QM48T25050 Series
Manufacturer: Bel Fuse Inc.
Beta
⌘K
DC DC CONVERTER 5V 125W
| Part | Power (Watts) | Voltage - Output 1 | Features | Current - Output (Max) [Max] | Control Features | Voltage - Input (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Type | Applications | Number of Outputs | Voltage - Isolation | Mounting Type | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Voltage - Input (Min) [Min] | Package / Case | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | 125 W | 5 V | OCP OTP OVP Remote On/Off UVLO | 25 A | Active Low Enable | 75 V | 85 °C | -40 C | Isolated Module | ITE (Commercial) | 1 | 2000 V | Through Hole | 2.28 " | 57.9 mm | 36.8 mm | 0.42 " | 10.7 mm | 1.45 in | 36 V | 8-DIP Module 1/4 Brick | |
 Bel Fuse Inc. | 125 W | 5 V | OCP OTP OVP Remote On/Off UVLO | 25 A | Active High Enable | 75 V | 85 °C | -40 C | Isolated Module | ITE (Commercial) | 1 | 2000 V | Through Hole | 2.28 " | 57.9 mm | 36.8 mm | 0.33 in | 8.3 mm | 1.45 in | 36 V | 8-DIP Module 1/4 Brick | |
 Bel Fuse Inc. | 125 W | 5 V | OCP OTP OVP Remote On/Off SCP UVLO | 25 A | 75 V | 85 °C | -40 °C | Isolated Module | ITE (Commercial) | 1 | 2000 V | Through Hole | 2.3 in | 58.4 mm | 36.8 mm | 0.33 in | 8.4 mm | 1.45 in | 36 V | 8-DIP Module 1/4 Brick | Quarter Brick | |
 Bel Fuse Inc. | 125 W | 5 V | OCP OTP OVP Remote On/Off UVLO | 25 A | Active Low Enable | 75 V | 85 °C | -40 C | Isolated Module | ITE (Commercial) | 1 | 2000 V | Through Hole | 2.3 in | 58.4 mm | 36.8 mm | 0.36 in | 9.1 mm | 1.45 in | 36 V | 8-DIP Module 1/4 Brick |
