ZUP20 Series

Catalog

PWR SUP BENCH PROG 0-20V 800W

Part	Voltage Regulation - Line	Ripple	Current Regulation - Load	Voltage Regulation - Load	Weight [custom]	Weight [custom]	Current Regulation - Line	Accuracy - Voltmeter; Ammeter	Features	Number of Outputs	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Type	Voltage - Output [Max]	Display Type	Number of Characters	Current - Output [Max]	Power (Watts)	Voltage - Supply [Min]	Voltage - Supply [Max]	Weight	Weight
TDK Corporation ZUP20-40/U	1 mV	5 mV	0.07 % 10 mA	2 mV	13 lbs	5.9 kg	0.01 % 5 mA	0.02% + 12mV	Memory Programmable RS232 and RS485 Interface	1	13.78 in	140 mm	350 mm	4.882 "	5.512 in	124 mm	Bench (AC to DC)	20 V	Digital	3	40 A	800 W	85 VAC/DC	265 VAC
TDK Corporation ZUP20-40	1 mV	5 mV	0.07 % 10 mA	2 mV	13 lbs	5.9 kg	0.01 % 5 mA	0.02% + 12mV	Memory Programmable RS232 and RS485 Interface	1	13.78 in	140 mm	350 mm	4.882 "	5.512 in	124 mm	Bench (AC to DC)	20 V	Digital	3	40 A	800 W	85 VAC/DC	265 VAC
TDK Corporation ZUP20-20/U	1 mV	5 mV	0.01 % 5 mA	2 mV			0.01 % 2 mA	0.02% + 12mV	Memory Programmable RS232 and RS485 Interface	1	13.78 in	124 mm	350 mm	2.756 "	4.882 "	70 mm	Bench (AC to DC)	20 V	Digital	3	20 A	400 W	85 VAC/DC	265 VAC	7.1 lbs	3.2 kg
TDK Corporation ZUP20-10	1 mV	5 mV	0.01 % 5 mA	2 mV			0.01 % 2 mA	0.02% + 12mV	Memory Programmable RS232 and RS485 Interface	1	13.78 in	124 mm	350 mm	2.756 "	4.882 "	70 mm	Bench (AC to DC)	20 V	Digital	3	10 A	200 Watts	85 VAC/DC	265 VAC	6.4 lbs	2.9 kg
