T9AV1 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RELAY GEN PURP
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Operate Time | Contact Rating (Current) | Load - Max Switching [Max] | Contact Form | Contact Material | Switching Voltage [Max] | Coil Type | Termination Style | Relay Type | Release Time | Mounting Type | Coil Resistance | Coil Current | Seal Rating | Coil Voltage | Must Operate Voltage | Coil Insulation | Must Release Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | -55 C | 85 °C | 15 ms | 30 A | 8310 VA | SPST-NO (1 Form A) | Silver Cadmium Oxide (AgCdO) | 277 VAC | Non Latching | PC Pin | General Purpose | 15 ms | Through Hole | |||||||
 TE Connectivity AMP Connectors | -55 C | 85 °C | 15 ms | 30 A | 8310 VA | SPST-NO (1 Form A) | Silver Cadmium Oxide (AgCdO) | 277 VAC | Non Latching | PC Pin Quick Connect - 0.250" (6.3mm) | General Purpose | 15 ms | Through Hole | 576 Ohms | 41.7 mA | Sealed - Flux Protection | 24 VDC | 18 VDC | Class F | 2.4 VDC |
TE Connectivity AMP Connectors | -55 C | 85 °C | 15 ms | 30 A | 8310 VA | SPST-NO (1 Form A) | Silver Cadmium Oxide (AgCdO) | 277 VAC | Non Latching | PC Pin | General Purpose | 15 ms | Through Hole | |||||||
TE Connectivity AMP Connectors | -55 C | 85 °C | 15 ms | 30 A | 8310 VA | SPST-NO (1 Form A) | Silver Cadmium Oxide (AgCdO) | 277 VAC | Non Latching | PC Pin | General Purpose | 15 ms | Through Hole | Sealed - Flux Protection | 22 VDC | 16.5 VDC | Class F | 2.2 VDC | ||
TE Connectivity AMP Connectors | -55 C | 85 °C | 15 ms | 30 A | 8310 VA | SPST-NO (1 Form A) | Silver Cadmium Oxide (AgCdO) | 277 VAC | Non Latching | PC Pin Quick Connect - 0.250" (6.3mm) | General Purpose | 15 ms | Through Hole | 576 Ohms | 41.7 mA | Sealed - Flux Protection | 24 VDC | 18 VDC | Class F | 2.4 VDC |
TE Connectivity AMP Connectors | -55 C | 85 °C | 15 ms | 30 A | 8310 VA | SPST-NO (1 Form A) | Silver Cadmium Oxide (AgCdO) | 277 VAC | Non Latching | PC Pin Quick Connect - 0.250" (6.3mm) | General Purpose | 15 ms | Through Hole | 160 Ohms | 0.075 A | Sealed - Flux Protection | 12 VDC | 9 VDC | Class F | 1.2 VDC |
