BPSF Series
Power Inductors - SMD Chilisin Power - Inductor (IND) Ferrite SMD Shielded Type
Manufacturer: Pulse Electronics
Catalog
Power Inductors - SMD Chilisin Power - Inductor (IND) Ferrite SMD Shielded Type
Beta
⌘K
Power Inductors - SMD Chilisin Power - Inductor (IND) Ferrite SMD Shielded Type
Power Inductors - SMD Chilisin Power - Inductor (IND) Ferrite SMD Shielded Type
Power Inductors - SMD Chilisin Power - Inductor (IND) Ferrite SMD Shielded Type
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | DC Resistance (DCR) [Max] | Inductance Frequency - Test | Inductance | Height - Seated (Max) [Max] | Height - Seated (Max) | Mounting Type | Current Rating (Amps) | Shielding | Package / Case | Tolerance | Current - Saturation (Isat) | Material - Core | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pulse Electronics | 125 °C | -40 C | 0.276 " | 0.276 in | 7 mm | 7 mm | 20 mOhm | 1 kHz | 3.3 µH | 0.189 " | 4.8 mm | Surface Mount | 2.3 A | Shielded | Nonstandard | 20 % | 2.5 A | Ferrite | ||
 Pulse Electronics | 125 °C | -40 C | 0.492 " | 0.492 " | 12.5 mm | 12.5 mm | 270 mOhm | 1 kHz | 220 µH | 0.228 " | Surface Mount | 1.2 A | Shielded | Nonstandard | 20 % | 720 mA | Ferrite | 5.8 mm | ||
Pulse Electronics | 125 °C | -40 C | 0.492 " | 0.492 " | 12.5 mm | 12.5 mm | 210 mOhm | 1 kHz | 150 µH | 0.27 in | Surface Mount | 1.5 A | Shielded | Nonstandard | 20 % | 1.2 A | Ferrite | 6.85 mm | ||
Pulse Electronics | 125 °C | -40 C | 0.492 " | 0.492 " | 12.5 mm | 12.5 mm | 190 mOhm | 1 kHz | 150 µH | 0.228 " | Surface Mount | 1.4 A | Shielded | Nonstandard | 20 % | 880 mA | Ferrite | 5.8 mm | ||
Pulse Electronics | 125 °C | -40 C | 0.492 " | 0.492 " | 12.5 mm | 12.5 mm | 31.6 mOhm | 1 kHz | 22 µH | 0.27 in | Surface Mount | 3.8 A | Shielded | Nonstandard | 20 % | 3.5 A | Ferrite | 6.85 mm | ||
 Pulse Electronics | 125 °C | -40 C | 0.492 " | 0.492 " | 12.5 mm | 12.5 mm | 11.7 mOhm | 1 kHz | 2 µH | 0.27 in | Surface Mount | 6.2 Amps | Shielded | Nonstandard | 30 % | 10 A | Ferrite | 6.85 mm | ||
Pulse Electronics | 125 °C | -40 C | 0.492 " | 0.492 " | 12.5 mm | 12.5 mm | 340 mOhm | 1 kHz | 330 µH | Surface Mount | Shielded | Nonstandard | 20 % | 900 mA | Ferrite | 0.309 " | 7.85 mm | |||
Pulse Electronics | 125 °C | -40 C | 0.492 " | 0.492 " | 12.5 mm | 12.5 mm | 39.5 mOhm | 1 kHz | 33 µH | Surface Mount | 3.4 A | Shielded | Nonstandard | 20 % | 3.2 A | Ferrite | 0.309 " | 7.85 mm | ||
Pulse Electronics | 125 °C | -40 C | 0.492 " | 0.492 " | 12.5 mm | 12.5 mm | 123 mOhm | 1 kHz | 100 µH | 0.27 in | Surface Mount | 1.9 A | Shielded | Nonstandard | 20 % | 1.6 A | Ferrite | 6.85 mm | ||
Pulse Electronics | 125 °C | -40 C | 0.492 " | 0.492 " | 12.5 mm | 12.5 mm | 11 mOhm | 1 kHz | 4.7 ÁH | Surface Mount | 6.3 A | Shielded | Nonstandard | 30 % | 7.8 A | Ferrite | 0.309 " | 7.85 mm |
