LTC1159 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

HIGH EFFICIENCY SYNCHRONOUS STEP-DOWN SWITCHING REGULATORS

Part	Supplier Device Package	Operating Temperature [Min]	Operating Temperature [Max]	Output Configuration	Duty Cycle (Max) [Max]	Topology	Control Features	Voltage - Supply (Vcc/Vdd) [Min]	Voltage - Supply (Vcc/Vdd) [Max]	Output Phases	Number of Outputs	Function	Frequency - Switching [Max]	Package / Case	Package / Case	Output Type	Mounting Type	Package / Case [y]	Package / Case [x]
Analog Devices Inc./Maxim Integrated LTC1159CS#TRPBF	16-SO	0 °C	70 °C	Positive or Negative	100 %	Buck	Current Limit Enable	4 V	40 V	1	1	Step-Down	250 kHz	16-SOIC	0.154 in 3.9 mm	Transistor Driver	Surface Mount
Analog Devices Inc./Maxim Integrated LTC1159CG-5#TRPBF	20-SSOP	0 °C	70 °C	Positive or Negative	100 %	Buck	Current Limit Enable	4 V	40 V	1	1	Step-Down	250 kHz	20-SSOP		Transistor Driver	Surface Mount	5.3 mm	0.209 in
Analog Devices Inc./Maxim Integrated LTC1159CS-3.3#TRPBF	16-SO	0 °C	70 °C	Positive or Negative	100 %	Buck	Current Limit Enable	4 V	40 V	1	1	Step-Down	250 kHz	16-SOIC	0.154 in 3.9 mm	Transistor Driver	Surface Mount
Analog Devices Inc./Maxim Integrated LTC1159CG-5#PBF	20-SSOP	0 °C	70 °C	Positive or Negative	100 %	Buck	Current Limit Enable	4 V	40 V	1	1	Step-Down	250 kHz	20-SSOP		Transistor Driver	Surface Mount	5.3 mm	0.209 in
Analog Devices Inc./Maxim Integrated LTC1159CG#PBF	20-SSOP	0 °C	70 °C	Positive or Negative	100 %	Buck	Current Limit Enable	4 V	40 V	1	1	Step-Down	250 kHz	20-SSOP		Transistor Driver	Surface Mount	5.3 mm	0.209 in
Analog Devices Inc./Maxim Integrated LTC1159IS-5#PBF	16-SO	-40 ¯C	85 C	Positive or Negative	100 %	Buck	Current Limit Enable	4 V	40 V	1	1	Step-Down	250 kHz	16-SOIC	0.154 in 3.9 mm	Transistor Driver	Surface Mount
Analog Devices Inc./Maxim Integrated LTC1159CG-3.3#PBF	20-SSOP	0 °C	70 °C	Positive or Negative	100 %	Buck	Current Limit Enable	4 V	40 V	1	1	Step-Down	250 kHz	20-SSOP		Transistor Driver	Surface Mount	5.3 mm	0.209 in
Analog Devices Inc./Maxim Integrated LTC1159IS-5#TRPBF	16-SO	-40 ¯C	85 C	Positive or Negative	100 %	Buck	Current Limit Enable	4 V	40 V	1	1	Step-Down	250 kHz	16-SOIC	0.154 in 3.9 mm	Transistor Driver	Surface Mount
Analog Devices Inc./Maxim Integrated LTC1159CS#PBF	16-SO	0 °C	70 °C	Positive or Negative	100 %	Buck	Current Limit Enable	4 V	40 V	1	1	Step-Down	250 kHz	16-SOIC	0.154 in 3.9 mm	Transistor Driver	Surface Mount
Analog Devices Inc./Maxim Integrated LTC1159CS-5#PBF	16-SO	0 °C	70 °C	Positive or Negative	100 %	Buck	Current Limit Enable	4 V	40 V	1	1	Step-Down	250 kHz	16-SOIC	0.154 in 3.9 mm	Transistor Driver	Surface Mount
