138 AML Series

Catalog

ELECTROLYTIC CAPACITOR, 138 AML SERIES, 220 ΜF, 63 V, ± 20%, AXIAL LEADED, 5000 HOURS @ 105°C

Part	Polarization	Lifetime	Ripple Current	Tolerance	Mounting Type	Size / Dimension Diameter	Size / Dimension Length	Capacitance	Voltage - Rated	Impedance	Operating Temperature (Min)	Operating Temperature (Max)	Package / Case	Applications	ESR (Equivalent Series Resistance)
Vishay Dale MAL213818221E3	Polar	10000 Hrs	560 mA 784 mA	20 %	Through Hole	0.492 in	1.181 in	220 µF	63 V	310 mOhm	-40 °C	105 °C	Axial Can	Automotive	500 mOhm
Vishay Dale MAL213814332E3	Polar	10000 Hrs	1.14 A 1.368 A	20 %	Through Hole	0.591 in	1.181 in	3300 µF	10 V	130 mOhms	-40 °C	105 °C	Axial Can	Automotive	160 mOhm
Vishay Dale MAL213819689E3	Polar	10000 Hrs	300 mA 420 mA	20 %	Through Hole	0.394 in	1.181 in	68 µF	100 VAC/DC	1.1 Ohms	-40 °C	105 °C	Axial Can	Automotive	1.7 Ohm
Vishay Dale MAL213828229E3	Polar	2000 Hrs	100 mA	20 %	Through Hole	0.256 in	0.709 in	22 µF	63 V	850 mOhm	-40 °C	105 °C	Axial Can	Automotive	5.1 Ohm
Vishay Dale MAL213816682E3	Polar	10000 Hrs	2.1 A 2.73 A	20 %	Through Hole	0.827 in	1.496 in	6800 µF	25 VAC	58 mOhms	-40 °C	105 °C	Axial Can	Automotive	68 mOhm
Vishay Dale MAL213817471E3	Polar	10000 Hrs	650 mA 910 mA	20 %	Through Hole	0.492 in	1.181 in	470 µF	40 V	230 mOhms	-40 °C	105 °C	Axial Can	Automotive	340 mOhm
Vishay Dale MAL213823222E3	Polar	2000 Hrs	640 mA	20 %	Through Hole	0.394 in	0.984 in	2200 ĄF	6.3 V	150 mOhms	-40 °C	105 °C	Axial Can	Automotive	210 mOhm
Vishay Dale MAL213817332E3	Polar	10000 Hrs	1.81 A 2.534 A	20 %	Through Hole	0.827 in	1.496 in	3300 µF	40 V	61 mOhms	-40 °C	105 °C	Axial Can	Automotive	79 mOhm
Vishay Dale MAL213835471E3	Polar	2000 Hrs	360 mA 468 mA	20 %	Through Hole	0.394 in	0.709 in	470 µF	16 V	0.34 Ohms	-40 °C	105 °C	Axial Can	Automotive	540 mOhm
Vishay Dale MAL213819221E3	Polar	10000 Hrs	650 mA 910 mA	20 %	Through Hole	0.591 in	1.181 in	220 µF	100 VAC/DC	370 mOhms	-40 °C	105 °C	Axial Can	Automotive	540 mOhm
