396-048 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 48POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Gender | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Flange Feature | Contact Material | Color | Read Out | Contact Finish | Mounting Type | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Pitch | Pitch | Number of Positions/Bay/Row | Features | Number of Positions | Termination | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | Cantilever | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Black | Dual | Gold | Through Hole | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 24 | Card Guides | 48 | Wire Wrap | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Black | Dual | Gold | Board Edge Straddle Mount | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 24 | Card Extender Card Guides | 48 | Solder | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Black | Dual | Gold | Through Hole | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 24 | Card Guides | 48 | Solder | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | Cantilever | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Black | Dual | Gold | Right Angle Through Hole | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 24 | Card Guides | 48 | Solder Wire Wrap | ||||
 EDAC Inc. | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | Cantilever | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Black | Single | Gold | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Non Specified - Single Edge | 3.18 mm | 0.125 in | 48 | 48 | Solder | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | Cantilever | Flush Mount Side Opening Unthreaded | Copper Alloy | Black | Dual | Gold | Board Edge Straddle Mount | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 24 | Card Extender | 48 | Solder | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | Cantilever | Flush Mount Top Opening Unthreaded | Copper Alloy | Black | Dual | Gold | Through Hole | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 24 | 48 | Wire Wrap | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | Cantilever | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Black | Dual | Gold | Through Hole | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 24 | Card Guides | 48 | Solder | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | Cantilever | Floating Bobbin Top Mount Opening | Copper Alloy | Black | Dual | Gold | Through Hole | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 24 | 48 | Solder | 0.116 " | 2.95 mm | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | Cantilever | Side Mount Opening Unthreaded | Copper Alloy | Black | Dual | Gold | Through Hole | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Non Specified - Dual Edge | 3.18 mm | 0.125 in | 24 | 48 | Solder | 0.128 " | 3.25 mm |
