SFR Series

Catalog

THICK FILM RESISTORS - SMD 0402 4.7OHMS 1% ANTI-SULFUR AEC-Q200

Part	Ratings	Composition	Number of Terminations [custom]	Package / Case	Supplier Device Package	Power (Watts)	Power (Watts)	Resistance	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Height - Seated (Max) [Max]	Height - Seated (Max)	Features	Temperature Coefficient	Tolerance	Height - Seated (Max) [Max]	Size / Dimension [y]	Package / Case
Rohm Semiconductor SFR01MZPF4R70	AEC-Q200	Thick Film	2	0402 (1005 Metric)	0402	0.063 W	0.0625 W	4.7 Ohms	155 C	-55 C	0.02 in	0.5 mm	0.039 "	1 mm	0.016 in	0.4 mm	Anti-Sulfur Automotive AEC-Q200	100 ppm/°C	1 %
Rohm Semiconductor SFR03EZPF3011		Thick Film	2	0603		0.1 W	0.1 W	3.01 kOhms	155 C	-55 C	0.031 in		0.063 "	1.6 mm	0.022 in		Anti-Sulfur Automotive AEC-Q200	100 ppm/°C	1 %	0.55 mm	0.8 mm	1608 Metric
Rohm Semiconductor SFR01MZPF4703		Thick Film	2	0402 (1005 Metric)	0402	0.063 W	0.0625 W	470 kOhms	155 C	-55 C	0.02 in	0.5 mm	0.039 "	1 mm	0.016 in	0.4 mm	Anti-Sulfur Automotive AEC-Q200	100 ppm/°C	1 %
Rohm Semiconductor SFR10EZPF1004		Thick Film	2	0805	0805	0.125 W	0.125 W	1 MOhms	155 C	-55 C	0.049 "	1.25 mm	0.079 in	2 mm	0.026 in		Anti-Sulfur Automotive AEC-Q200	100 ppm/°C	1 %	0.65 mm
Rohm Semiconductor SFR01MZPF3302		Thick Film	2	0402 (1005 Metric)	0402	0.063 W	0.0625 W	33000 Ohms	155 C	-55 C	0.02 in	0.5 mm	0.039 "	1 mm	0.016 in	0.4 mm	Anti-Sulfur Automotive AEC-Q200	100 ppm/°C	1 %
Rohm Semiconductor SFR03EZPF4702		Thick Film	2	0603		0.1 W	0.1 W	47000 Ohms	155 C	-55 C	0.031 in		0.063 "	1.6 mm	0.022 in		Anti-Sulfur Automotive AEC-Q200	100 ppm/°C	1 %	0.55 mm	0.8 mm	1608 Metric
Rohm Semiconductor SFR03EZPF4701		Thick Film	2	0603		0.1 W	0.1 W	4.7 kOhms	155 C	-55 C	0.031 in		0.063 "	1.6 mm	0.022 in		Anti-Sulfur Automotive AEC-Q200	100 ppm/°C	1 %	0.55 mm	0.8 mm	1608 Metric
Rohm Semiconductor SFR01MZPF1800		Thick Film	2	0402 (1005 Metric)	0402	0.063 W	0.0625 W	180 Ohms	155 C	-55 C	0.02 in	0.5 mm	0.039 "	1 mm	0.016 in	0.4 mm	Anti-Sulfur Automotive AEC-Q200	100 ppm/°C	1 %
Rohm Semiconductor SFR01MZPF1504		Thick Film	2	0402 (1005 Metric)	0402	0.063 W	0.0625 W	1.5 MOhms	155 C	-55 C	0.02 in	0.5 mm	0.039 "	1 mm	0.016 in	0.4 mm	Anti-Sulfur Automotive AEC-Q200	100 ppm/°C	1 %
Rohm Semiconductor SFR03EZPF3300		Thick Film	2	0603		0.1 W	0.1 W	330 Ohms	155 C	-55 C	0.031 in		0.063 "	1.6 mm	0.022 in		Anti-Sulfur Automotive AEC-Q200	100 ppm/°C	1 %	0.55 mm	0.8 mm	1608 Metric
