3112A Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 2COND 20AWG YLW SHLD
| Part | Shield Coverage | Shield Material | Jacket Color | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Voltage | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Cable Type | Jacket (Insulation) Material | Length | Length | Conductor Strand | Operating Temperature [Min] | Operating Temperature [Max] | Number of Conductors | Shield Type | Conductor Insulation | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum | Yellow | 5.74 mm | 0.226 in | 300 VDC | 0.94 mm | 0.037 in | Multi-Conductor | Poly-Vinyl Chloride (PVC) | 304.8 m | 1000 ft | Solid | -30 ░C | 105 ░C | 2 | Foil | Poly-Vinyl Chloride (PVC) | 20 AWG |
