Coupled Inductors 1.0uH 11A 0.0052ohms
Coupled Inductors 1.0uH 11A 0.0052ohms
| Part | Current Saturation - Parallel | Current Rating - Parallel | Inductance - Connected In Parallel | Current Rating - Series | Mounting Type | Number of Coils | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Package / Case | Shielding | Operating Temperature [Max] | Operating Temperature [Min] | Tolerance | Inductance - Connected In Series | Height | Height | Current Saturation - Series | DC Resistance (DCR) - Parallel [Max] | DC Resistance (DCR) - Series [Max] | DC Resistance (DCR) - Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Eaton - Electronics Division | 11.25 A | 9.23 A | 1.39 µH | 4.62 A | Surface Mount | 2 | 0.55 " | 0.55 in | 13.97 mm | 13.97 mm | Nonstandard | Unshielded | 85 °C | -40 C | 25 % | 5.57 µH | 0.25 in | 6.35 mm | 5.63 A | 5.2 mOhm | 20.7 mOhm | |
 Eaton - Electronics Division | 2.65 A | 3.02 A | 25.14 µH | 1.51 A | Surface Mount | 2 | 0.55 " | 0.55 in | 13.97 mm | 13.97 mm | Nonstandard | Unshielded | 85 °C | -40 C | 25 % | 100.51 µH | 0.25 in | 6.35 mm | 1.32 A | 48 mOhm | 193 mOhm |
