TPS78230 Series

Catalog

IC REG LINEAR 3V 150MA 6WSON

Part	PSRR [Min]	PSRR [Max]	Mounting Type	Current - Output	Supplier Device Package	Control Features	Protection Features	Number of Regulators	Current - Supply (Max) [Max]	Output Configuration	Voltage Dropout (Max) [Max]	Voltage - Input (Max) [Max]	Current - Quiescent (Iq)	Output Type	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Channels per IC	Utilized IC / Part	Voltage - Input [Min]	Voltage - Input [Max]	Regulator Type	Voltage - Output	Board Type	Supplied Contents	Grade	Qualification
Texas Instruments TPS78230DRVT	15 dB	40 dB	Surface Mount	150 mA	6-WSON (2x2)	Enable	Over Current Over Temperature Reverse Polarity	1	8 µA	Positive	0.25 V	5.5 V	1.3 µA	1.81 mOhm	125 °C	-40 °C
Texas Instruments TPS78230DDCT	15 dB	40 dB	Surface Mount	150 mA	SOT-23-THIN	Enable	Over Current Over Temperature Reverse Polarity	1	8 µA	Positive	0.25 V	5.5 V	1.3 µA	1.81 mOhm	125 °C	-40 °C	SOT-23-5 Thin TSOT-23-5
Texas Instruments TPS78230DDCR	15 dB	40 dB	Surface Mount	150 mA	SOT-23-THIN	Enable	Over Current Over Temperature Reverse Polarity	1	8 µA	Positive	0.25 V	5.5 V	1.3 µA	1.81 mOhm	125 °C	-40 °C	SOT-23-5 Thin TSOT-23-5
Texas Instruments TPS78230EVM-445				150 mA														1 - Single	TPS78230	2.2 V	5.5 V	Positive Fixed	3 V	Fully Populated	Board(s)
Texas Instruments TPS78230QDRVRQ1	15 dB	40 dB	Surface Mount	150 mA	6-WSON (2x2)	Enable	Over Current Over Temperature Reverse Polarity	1	8 µA	Positive	0.25 V	5.5 V	1.3 µA	1.81 mOhm	125 °C	-40 °C										Automotive	AEC-Q100
