KHJ Series
Manufacturer: Chemi-Con
Beta
⌘K
ALUMINUM ELECTROLYTIC CAPACITORS - SNAP IN 420UF 420V
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Applications | Voltage - Rated | Polarization | Lead Spacing | Lead Spacing | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Ripple Current @ Low Frequency | Tolerance | Package / Case | Lifetime @ Temp. | Size / Dimension | Size / Dimension [diameter] | Capacitance | Ripple Current @ High Frequency | Size / Dimension [diameter] | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Chemi-Con | -40 C | 105 ░C | Through Hole | General Purpose | 420 V | Polar | 0.394 in | 10 mm | 2.106 in | 53.5 mm | 2.96 A | 20 % | Radial Can - Snap-In | 3000 Hrs | 30 mm | 1.181 " | 420 µF | 4.3216 A | |||
 Chemi-Con | -40 C | 105 ░C | Through Hole | General Purpose | 420 V | Polar | 0.394 in | 10 mm | 2.57 A | 20 % | Radial Can - Snap-In | 3000 Hrs | 1.378 " | 350 µF | 3.7522 A | 35 mm | 1.476 in | 37.5 mm | |||
 Chemi-Con | -40 C | 105 ░C | Through Hole | General Purpose | 400 V | Polar | 0.394 in | 10 mm | 2.106 in | 53.5 mm | 4.15 A | 20 % | Radial Can - Snap-In | 3000 Hrs | 1.378 " | 680 µF | 6.059 A | 35 mm |
