SDT-SS Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RELAY GEN PURPOSE SPST 10A 6V
| Part | Coil Resistance | Must Operate Voltage | Release Time | Contact Form | Relay Type | Operate Time | Switching Voltage | Coil Type | Contact Rating (Current) | Contact Material | Termination Style | Approval Agency | Must Release Voltage | Load - Max Switching | Seal Rating | Coil Current | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Coil Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 66.7 Ohms | 4.5 VDC | 8 ms | SPST-NO (1 Form A) | General Purpose | 15 ms | 24 VDC 250 VAC | Non Latching | 10 A | Silver Tin Oxide Indium Oxide (AgSnOInO) | PC Pin | CSA SEMKO SEV TUV UL | 0.6 VDC | 240 W 2500 VA | Sealed - Flux Protection | 88 mA | Through Hole | -30 ░C | 60 °C | |
 TE Connectivity AMP Connectors | 267 Ohms | 9 VDC | 8 ms | SPST-NO (1 Form A) | General Purpose | 15 ms | 24 VDC 250 VAC | Non Latching | 10 A | Silver Tin Oxide Indium Oxide (AgSnOInO) | PC Pin | CSA SEMKO SEV TUV UL | 1.2 VDC | 240 W 2500 VA | Sealed - Flux Protection | 44.4 mA | Through Hole | -30 ░C | 60 °C | 12 VDC |
