BFC2378 Series

Catalog

CAPACITOR,MET POLYPROPYLENE,43NF,2KVDC,5-% TOL,5+% TOL

Part	Package / Case	Size / Dimension Width	Size / Dimension Length	Height - Seated (Max)	Voltage Rating - AC	Capacitance	Applications	Termination	Tolerance	Voltage Rating - DC	Operating Temperature (Min)	Operating Temperature (Max)	Lead Spacing	Mounting Type	Features	Dielectric Material
Vishay Dale BFC237894433	Radial	0.591 in	1.24 in	0.984 in	600 VAC	0.043 µF	DV/DT High Pulse	PC Pins	5 %	2 kVDC	-55 °C	85 °C	1.083 in	Through Hole	Long Life	Metallized Polypropylene (PP)
Vishay Dale BFC237872123	Radial	0.236 in	1.024 in	0.61 in	300 V	0.012 µF	DV/DT High Pulse	PC Pins	5 %	1 kV	-55 °C	85 °C	0.886 in	Through Hole	Long Life	Metallized Polypropylene (PP)
Vishay Dale BFC237865243	Radial	0.197 in	0.689 in	0.728 in	300 V	0.024 µF	DV/DT High Pulse	PC Pins	5 %	630 V	-55 °C	85 °C	0.591 in	Through Hole	Long Life	Metallized Polypropylene (PP)
Vishay Dale BFC237864223	Radial	0.197 in	0.689 in	0.433 in	300 V	0.022 µF	DV/DT High Pulse	PC Pins	5 %	630 V	-55 °C	85 °C	0.591 in	Through Hole	Long Life	Metallized Polypropylene (PP)
Vishay Dale BFC237874123	Radial	0.236 in	1.024 in	0.61 in	300 V	0.012 µF	DV/DT High Pulse	PC Pins	5 %	1 kV	-55 °C	85 °C	0.886 in	Through Hole	Long Life	Metallized Polypropylene (PP)
Vishay Dale BFC237862394	Radial	0.433 in	1.22 in	0.827 in	300 V	0.39 µF	DV/DT High Pulse	PC Pins	5 %	630 V	-55 °C	85 °C	1.083 in	Through Hole	Long Life	Metallized Polypropylene (PP)
Vishay Dale BFC237892362	Radial	0.236 in	1.024 in	0.61 in	600 VAC	3600 pF	DV/DT High Pulse	PC Pins	5 %	2 kVDC	-55 °C	85 °C	0.886 in	Through Hole	Long Life	Metallized Polypropylene (PP)
Vishay Dale BFC237872124	Radial	0.433 in	1.24 in	0.827 in	300 V	0.12 µF	DV/DT High Pulse	PC Pins	5 %	1 kV	-55 °C	85 °C	1.083 in	Through Hole	Long Life	Metallized Polypropylene (PP)
Vishay Dale BFC237864274	Radial	0.354 in	1.24 in	0.748 in	300 V	0.27 µF	DV/DT High Pulse	PC Pins	5 %	630 V	-55 °C	85 °C	1.083 in	Through Hole	Long Life	Metallized Polypropylene (PP)
Vishay Dale BFC237875223	Radial	0.236 in	1.024 in	0.728 in	300 V	0.022 µF	DV/DT High Pulse	PC Pins	5 %	1 kV	-55 °C	85 °C	0.886 in	Through Hole	Long Life	Metallized Polypropylene (PP)
