APT1232 Series

Catalog

APT PHOTOTRIAC ROHS COMPLIANT: YES

Part	Package / Case	Voltage - Forward (Vf) (Typ)	Voltage - Off State	Static dV/dt (Min) [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Current - On State (It (RMS)) (Max) [Max]	Mounting Type	Current - DC Forward (If) (Max) [Max]	Turn On Time [Max]	Current - LED Trigger (Ift) (Max) [Max]	Current - Hold (Ih)	Number of Channels [custom]	Supplier Device Package	Output Type	Approval Agency	Package / Case	Package / Case	Package / Case
Panasonic Electronic Components APT1232WA	6-SMD (5 Leads) Gull Wing	1.21 V	600 V	500 V/µs	-40 C	100 °C	100 mA	Surface Mount	50 mA	100 µs	10 mA	3.5 mA	1	6-DIP Gull Wing	Triac	cUR VDE
Panasonic Electronic Components APT1232A	6-SMD (5 Leads) Gull Wing	1.21 V	600 V	500 V/µs	-40 C	100 °C	100 mA	Surface Mount	50 mA	100 µs	10 mA	3.5 mA	1	6-DIP Gull Wing	Triac	cUR VDE
Panasonic Electronic Components APT1232W	6-DIP	1.21 V	600 V	500 V/µs	-40 C	100 °C	100 mA	Through Hole	50 mA	100 µs	10 mA	3.5 mA	1	6-DIP	Triac	cUR VDE	5 Leads	10.16 mm	10.16 mm
Panasonic Electronic Components APT1232AZ	5-SMD Gull Wing 6-SMD (5 Leads) Gull Wing	1.21 V	600 V	500 V/µs	-40 C	100 °C	100 mA	Surface Mount	50 mA	100 µs	10 mA	3.5 mA	1	6-DIP Gull Wing	Triac	cUR VDE
Panasonic Electronic Components APT1232AX	6-SMD (5 Leads) Gull Wing	1.21 V	600 V	500 V/µs	-40 C	100 °C	100 mA	Surface Mount	50 mA	100 µs	10 mA	3.5 mA	1	6-DIP Gull Wing	Triac	cUR VDE
