807-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 50POS 0.156
| Part | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Card Type | Read Out | Contact Material | Number of Positions/Bay/Row | Termination Rows | Number of Rows [custom] | Flange Feature | Termination | Pitch | Pitch | Gender | Color | Material - Insulation | Contact Finish | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 50 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | Copper Alloy | 25 | 1 | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Solder | 3.96 mm | 0.156 in | Female | Green | Diallyl Phthalate (DAP) | Gold | Through Hole | 0.25 Ám | 10 Áin | Semi Bellows | 125 °C | -40 C | |||
 EDAC Inc. | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Single | Copper Alloy | 25 | 1 | Wire Wrap | 3.96 mm | 0.156 in | Female | Green | Diallyl Phthalate (DAP) | Gold | Through Hole | 0.25 Ám | 10 Áin | Semi Bellows | 125 °C | -40 C | 1 | ||||
 EDAC Inc. | 50 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | Copper Alloy | 25 | 1 | 2 | Floating Bobbin Flush Mount | Solder Eyelet(s) | 3.96 mm | 0.156 in | Female | Green | Diallyl Phthalate (DAP) | Gold | Through Hole | 0.25 Ám | 10 Áin | Semi Bellows | 125 °C | -40 C | 0.116 " | 2.95 mm | |
 EDAC Inc. | 50 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | Copper Alloy | 25 | 1 | 2 | Solder Eyelet(s) | 3.96 mm | 0.156 in | Female | Green | Diallyl Phthalate (DAP) | Tin | Through Hole | Semi Bellows | 125 °C | -40 C | ||||||
 EDAC Inc. | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Single | Copper Alloy | 25 | 1 | Flush Mount Top Opening Unthreaded | Solder | 3.96 mm | 0.156 in | Female | Green | Diallyl Phthalate (DAP) | Tin | Through Hole | Semi Bellows | 125 °C | -40 C | 1 | 0.156 " | 3.96 mm | |||
 EDAC Inc. | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Single | Copper Alloy | 25 | 1 | Flush Mount M3 Threaded Insert Top Opening | Solder | 3.96 mm | 0.156 in | Female | Green | Diallyl Phthalate (DAP) | Tin | Through Hole | Semi Bellows | 125 °C | -40 C | 1 | |||||
 EDAC Inc. | 50 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | Copper Alloy | 25 | 1 | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Solder Eyelet(s) | 3.96 mm | 0.156 in | Female | Green | Diallyl Phthalate (DAP) | Gold | Through Hole | 0.25 Ám | 10 Áin | Semi Bellows | 125 °C | -40 C | |||
 EDAC Inc. | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Single | Copper Alloy | 25 | 1 | Flush Mount Top Opening Unthreaded | Solder | 3.96 mm | 0.156 in | Female | Green | Diallyl Phthalate (DAP) | Gold | Through Hole | 0.25 Ám | 10 Áin | Semi Bellows | 125 °C | -40 C | 1 | 0.128 " | 3.25 mm | |
 EDAC Inc. | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Single | Copper Alloy | 25 | 1 | 4-40 Flush Mount Threaded Insert Top Opening | Solder | 3.96 mm | 0.156 in | Female | Green | Diallyl Phthalate (DAP) | Gold | Right Angle Through Hole | 0.25 Ám | 10 Áin | Semi Bellows | 125 °C | -40 C | 1 | |||
 EDAC Inc. | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Single | Copper Alloy | 25 | 1 | Flush Mount M3 Threaded Insert Top Opening | Wire Wrap | 3.96 mm | 0.156 in | Female | Green | Diallyl Phthalate (DAP) | Tin | Through Hole | Semi Bellows | 125 °C | -40 C | 1 |
