Schaffner FN3042 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
FN3042-10-61-C20-R65
| Part | Applications | Approval Agency | Voltage - Rated AC (Phase to Ground/Neutral) | Frequency - Operating | Filter Type | Termination Style | Current | Mounting Type | Voltage - Rated AC (Phase to Phase) | Configuration | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Medical | CE CSA ENEC UKCA UR | 305 V | 60 Hz | Three Phase (Delta) | Terminal Block | 10 A | Chassis Mount | 530 V | Single Stage | -40 C | 100 °C |
TE Connectivity AMP Connectors | Medical | CE CSA ENEC UKCA UR | 305 V | 60 Hz | Three Phase (Delta) | Terminal Block | 30 A | Chassis Mount | 530 V | Single Stage | -40 C | 100 °C |
 TE Connectivity AMP Connectors | General Purpose | CE CSA ENEC UKCA UR | 305 V | 60 Hz | Three Phase (Delta) | Terminal Block | 10 A | DIN Rail | 530 V | Single Stage | -40 C | 100 °C |
 TE Connectivity AMP Connectors | General Purpose | CE CSA ENEC UKCA UR | 305 V | 60 Hz | Three Phase (Delta) | Terminal Block | 20 A | DIN Rail | 530 V | Single Stage | -40 C | 100 °C |
TE Connectivity AMP Connectors | Medical | CE CSA ENEC UKCA UR | 305 V | 60 Hz | Three Phase (Delta) | Terminal Block | 30 A | Chassis Mount | 530 V | Single Stage | -40 C | 100 °C |
TE Connectivity AMP Connectors | Medical | CE CSA ENEC UKCA UR | 305 V | 60 Hz | Three Phase (Delta) | Terminal Block | 10 A | Chassis Mount | 530 V | Single Stage | -40 C | 100 °C |
 TE Connectivity AMP Connectors | General Purpose | CE CSA ENEC UKCA UR | 305 V | 60 Hz | Three Phase (Delta) | Terminal Block | 30 A | DIN Rail | 530 V | Single Stage | -40 C | 100 °C |
TE Connectivity AMP Connectors | General Purpose | CE CSA ENEC UKCA UR | 305 V | 60 Hz | Three Phase (Delta) | Terminal Block | 30 A | DIN Rail | 530 V | Single Stage | -40 C | 100 °C |
TE Connectivity AMP Connectors | Medical | CE CSA ENEC UKCA UR | 305 V | 60 Hz | Three Phase (Delta) | Terminal Block | 20 A | Chassis Mount | 530 V | Single Stage | -40 C | 100 °C |
TE Connectivity AMP Connectors | General Purpose | CE CSA ENEC UKCA UR | 305 V | 60 Hz | Three Phase (Delta) | Terminal Block | 20 A | DIN Rail | 530 V | Single Stage | -40 C | 100 °C |
