110-A-11 Series
Manufacturer: WECO Electrical Connectors Inc.
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
PLUG PLUG-IN SCREW 3POS 3.5MM PI
| Part | Wire Gauge or Range - mm² | Positions Per Level | Voltage - UL | Wire Gauge or Range - AWG (Min) | Wire Gauge or Range - AWG (Max) | Number of Positions | Type | Contact Mating Finish | Pitch | Termination Style | Number of Levels | Operating Temperature (Min) | Operating Temperature (Max) | Plug Wire Entry Angle | Current - UL | Mounting Type | Color | Material Flammability Rating | Housing Material | Insulation Height | Contact Material | Wire Strip Length | Torque - Screw | Screw Size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 WECO Electrical Connectors Inc. | 1.5 mm² | 3 | 300 V | 16 AWG | 30 AWG | 3 | Female Sockets Plug | Tin | 0.138 in | Screw - Rising Cage Clamp | 1 | -40 °C | 105 °C | 180 ° | 8 A | Free Hanging (In-Line) | Gray | UL94 V-0 | Nylon PA Polyamide | 0.43 in | Copper Alloy | 6 mm | 0.2 Nm | M2 |
