LQM2HPN Series

Manufacturer: Murata Power Solutions Inc.

Catalog

FIXED IND 2.2UH 1.3A 100MOHM SMD

Part	Current Rating (Amps)	Inductance Frequency - Test	Frequency - Self Resonant	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Shielding	Type	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Package / Case	Material - Core	Tolerance	Supplier Device Package	Supplier Device Package	DC Resistance (DCR)	Mounting Type	Inductance	Operating Temperature [Min]	Operating Temperature [Max]	Current - Saturation (Isat)	DC Resistance (DCR) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
Murata Power Solutions Inc. LQM2HPN2R2MG0L	1.3 A	1 MHz	40 MHz	0.098 "	2 mm	2.5 mm	0.079 in	Shielded	Multilayer	0.039 "	1 mm	1008	Ferrite	20 %	2520	1008	100 mOhm	Surface Mount	2.2 µH	-55 °C	125 °C
Murata Power Solutions Inc. LQM2HPNR47MCHL
Murata Power Solutions Inc. LQM2HPNR47MGHL	2.6 A	1 MHz	80 MHz	0.098 "	2 mm	2.5 mm	0.079 in	Shielded	Multilayer	0.039 "	1 mm	1008	Ferrite	20 %	2520	1008	50 mOhm	Surface Mount	470 nH	-40 °C	85 °C	4.5 A
Murata Power Solutions Inc. LQM2HPN1R5MEHL	1.45 A	1 MHz	40 MHz	0.098 "	2 mm	2.5 mm	0.079 in	Shielded	Multilayer			1008	Ferrite	20 %	2520	1008		Surface Mount	1.5 µH	-40 °C	85 °C	1.2 A	150 mOhm	0.8 mm	0.031 "
Murata Power Solutions Inc. LQM2HPNR47MG0L	1.8 A	1 MHz	100 MHz	0.098 "	2 mm	2.5 mm	0.079 in	Shielded	Multilayer	0.039 "	1 mm	1008	Ferrite	20 %	2520	1008	50 mOhm	Surface Mount	470 nH	-55 °C	125 °C
Murata Power Solutions Inc. LQM2HPNR24MCHL
Murata Power Solutions Inc. LQM2HPN2R2MEHL	1.3 A	1 MHz	30 MHz	0.098 "	2 mm	2.5 mm	0.079 in	Shielded	Multilayer			1008	Ferrite	20 %	2520	1008		Surface Mount	2.2 µH	-40 °C	85 °C	800 mA	188 mOhm	0.8 mm	0.031 "
Murata Power Solutions Inc. LQM2HPN1R5MGHL	2 A	1 MHz	40 MHz	0.098 "	2 mm	2.5 mm	0.079 in	Shielded	Multilayer	0.039 "	1 mm	1008	Ferrite	20 %	2520	1008		Surface Mount	1.5 µH	-40 °C	85 °C		81 mOhm
Murata Power Solutions Inc. LQM2HPN4R7MGCL	800 mA	1 MHz	25 MHz	0.098 "	2 mm	2.5 mm	0.079 in	Shielded	Multilayer	0.039 "	1 mm	1008	Ferrite	20 %	2520	1008	225 mOhm	Surface Mount	4.7 ÁH	-55 °C	125 °C
Murata Power Solutions Inc. LQM2HPN1R0MJCL	1.5 A	1 MHz	50 MHz	0.098 "	2 mm	2.5 mm	0.079 in	Shielded	Multilayer	0.039 "	1 mm	1008		20 %	2520	1008		Surface Mount	1 µH	-55 °C	125 °C		108 mOhm
