DO1608C Series
Manufacturer: Coilcraft
Beta
⌘K
POWER INDUCTORS - SMD 10UH SHLD 20% 1.5A 160MOHMS
| Part | Ratings | Package / Case | Material - Core | Frequency - Self Resonant | Inductance Frequency - Test | Current Rating (Amps) | Current - Saturation (Isat) | DC Resistance (DCR) [Max] | Type | Inductance | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Shielding | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Tolerance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Coilcraft | AEC-Q200 | Nonstandard | Ferrite | 35 MHz | 100 kHz | 1.5 A | 1.1 A | 160 mOhm | Wirewound | 10 µH | 0.26 in | 4.45 mm | 0.175 " | 6.6 mm | Unshielded | Surface Mount | 85 °C | -40 C | 20 % |
