G8P-1C Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
RELAY GEN PURPOSE SPDT 10A 110V
| Part | Termination Style | Release Time | Operating Temperature [Max] | Operating Temperature [Min] | Relay Type | Contact Form | Load - Max Switching | Switching Voltage | Contact Material | Mounting Type | Coil Insulation | Contact Rating (Current) | Coil Type | Coil Resistance | Coil Current | Must Release Voltage | Approval Agency | Must Operate Voltage | Coil Voltage | Operate Time | Seal Rating | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Omron Electronics Inc-EMC Div | PC Pin | 10 ms | 105 ░C | -55 °C | General Purpose | SPDT (1 Form C) | 280 W 2500 VA | 28 VDC 250 VAC | Cadmium Free Silver Alloy | Through Hole | Class F | 10 A | Non Latching | 12.4 kOhms | 9 mA | 11 VDC | CSA UR | 82.5 VDC | 110 VDC | 15 ms | ||
 Omron Electronics Inc-EMC Div | PC Pin | 10 ms | 105 ░C | -55 °C | General Purpose | SPDT (1 Form C) | 280 W 2500 VA | 28 VDC 250 VAC | Silver Cadmium Oxide (AgCdO) | Through Hole | Class F | 10 A | Non Latching | 155 Ohms | 77 mA | 1.2 VDC | CSA UR | 9 VDC | 12 VDC | 15 ms | Sealed - Fully | |
 Omron Electronics Inc-EMC Div | Quick Connect - 0.187"/0.250" | 10 ms | 105 ░C | -55 °C | General Purpose | SPDT (1 Form C) | 280 W 2500 VA | 28 VDC 250 VAC | Cadmium Free Silver Alloy | Chassis Mount | Class F | 10 A | Non Latching | 660 Ohms | 36 mA | 2.4 VDC | CSA UR | 18 VDC | 24 VDC | 15 ms | ||
Omron Electronics Inc-EMC Div | PC Pin | 10 ms | 105 ░C | -55 °C | General Purpose | SPDT (1 Form C) | 280 W 2500 VA | 28 VDC 250 VAC | Cadmium Free Silver Alloy | Through Hole | Class F | 10 A | Non Latching | 27 Ohms | 185 mA | 0.5 VDC | CSA UR | 3.75 VDC | 5 VDC | 15 ms | ||
Omron Electronics Inc-EMC Div | PC Pin | 10 ms | 85 °C | -55 °C | General Purpose | SPDT (1 Form C) | 280 W 2500 VA | 28 VDC 250 VAC | Silver Cadmium Oxide (AgCdO) | Through Hole | Class B | 10 A | Non Latching | 155 Ohms | 77 mA | 1.2 VDC | CSA UR | 9 VDC | 12 VDC | 15 ms | Sealed - Fully | |
 Omron Electronics Inc-EMC Div | PC Pin Quick Connect | 10 ms | 105 ░C | -55 °C | General Purpose | SPDT (1 Form C) | 280 W 2500 VA | 28 VDC 250 VAC | Silver Cadmium Oxide (AgCdO) | Through Hole | Class F | 10 A | Non Latching | 660 Ohms | 36 mA | 2.4 VDC | CSA UR | 18 VDC | 24 VDC | 15 ms | Sealed - Fully | 0.25 in |
Omron Electronics Inc-EMC Div | PC Pin Quick Connect | 10 ms | 105 ░C | -55 °C | General Purpose | SPDT (1 Form C) | 280 W 2500 VA | 28 VDC 250 VAC | Cadmium Free Silver Alloy | Through Hole | Class F | 10 A | Non Latching | 12.4 kOhms | 9 mA | 11 VDC | CSA UR | 82.5 VDC | 110 VDC | 15 ms | 0.25 in | |
Omron Electronics Inc-EMC Div | PC Pin | 10 ms | 85 °C | -55 °C | General Purpose | SPDT (1 Form C) | 280 W 2500 VA | 28 VDC 250 VAC | Silver Tin Indium (AgSnIn) | Through Hole | Class B | 10 A | Non Latching | 660 Ohms | 36 mA | 2.4 VDC | CSA UR | 18 VDC | 24 VDC | 15 ms | Sealed - Fully | |
Omron Electronics Inc-EMC Div | Quick Connect - 0.187"/0.250" | 10 ms | 105 ░C | -55 °C | General Purpose | SPDT (1 Form C) | 280 W 2500 VA | 28 VDC 250 VAC | Cadmium Free Silver Alloy | Chassis Mount | Class F | 10 A | Non Latching | 12.4 kOhms | 9 mA | 11 VDC | CSA UR | 82.5 VDC | 110 VDC | 15 ms | ||
Omron Electronics Inc-EMC Div | Quick Connect - 0.187"/0.250" | 10 ms | 105 ░C | -55 °C | General Purpose | SPDT (1 Form C) | 280 W 2500 VA | 28 VDC 250 VAC | Cadmium Free Silver Alloy | Chassis Mount | Class F | 10 A | Non Latching | 155 Ohms | 77 mA | 1.2 VDC | CSA UR | 9 VDC | 12 VDC | 15 ms |
