896-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 14POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Read Out | Contact Finish | Contact Material | Features | Card Type | Number of Positions | Gender | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Color | Contact Type | Mounting Type | Number of Rows [custom] | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Dual | Gold | Copper Alloy | Card Extender | Non Specified - Dual Edge | 14 | Female | 7 | 125 °C | -40 C | Solder Eyelet(s) | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Black | Cantilever | Board Edge Straddle Mount | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Single | Gold | Copper Alloy | Non Specified - Single Edge | 14 | Female | 14 | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Black | Cantilever | Through Hole | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Dual | Gold | Copper Alloy | Card Extender | Non Specified - Dual Edge | 14 | Female | 7 | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Black | Cantilever | Board Edge Straddle Mount | 2 | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Dual | Gold | Copper Alloy | Non Specified - Dual Edge | 14 | Female | 7 | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Black | Cantilever | Right Angle Through Hole | 2 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Dual | Gold | Copper Alloy | Card Extender | Non Specified - Dual Edge | 14 | Female | 7 | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Black | Cantilever | Board Edge Straddle Mount | 2 | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Dual | Gold | Copper Alloy | Card Extender | Non Specified - Dual Edge | 14 | Female | 7 | 125 °C | -40 C | Solder Eyelet(s) | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Black | Cantilever | Board Edge Straddle Mount | 2 | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Dual | Gold | Copper Alloy | Non Specified - Dual Edge | 14 | Female | 7 | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Black | Cantilever | Right Angle Through Hole | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Single | Gold | Copper Alloy | Non Specified - Single Edge | 14 | Female | 14 | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Black | Cantilever | Through Hole | 1 | 1 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Dual | Gold | Copper Alloy | Non Specified - Dual Edge | 14 | Female | 7 | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Black | Cantilever | Through Hole | 2 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Dual | Gold | Copper Alloy | Non Specified - Dual Edge | 14 | Female | 7 | 125 °C | -40 C | Wire Wrap | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | Black | Cantilever | Through Hole | 2 |
