325-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 44POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Mounting Type | Card Thickness | Card Thickness | Contact Finish | Color | Number of Rows [custom] | Card Type | Number of Positions/Bay/Row | Gender | Number of Positions | Read Out | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Pitch | Pitch | Termination | Contact Type | Termination Rows | Number of Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 3.18 mm | 0.125 in | Gold | Green | 2 | Non Specified - Dual Edge | 22 | Female | 44 | Dual | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Copper Alloy | 0.1 " | 2.54 mm | Wire Wrap | Cantilever | |||||
EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | 3.18 mm | 0.125 in | Gold | Green | Non Specified - Single Edge | 44 | Female | 44 | Single | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Copper Alloy | 0.1 " | 2.54 mm | Solder Eyelet(s) | Cantilever | 1 | 1 | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 3.18 mm | 0.125 in | Gold | Green | 2 | Non Specified - Dual Edge | 22 | Female | 44 | Dual | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Copper Alloy | 0.1 " | 2.54 mm | Solder Eyelet(s) | Cantilever | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | 3.18 mm | 0.125 in | Gold | Green | Non Specified - Single Edge | 44 | Female | 44 | Single | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Copper Alloy | 0.1 " | 2.54 mm | Wire Wrap | Cantilever | 1 | 1 | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 3.18 mm | 0.125 in | Gold | Green | 2 | Non Specified - Dual Edge | 22 | Female | 44 | Dual | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Copper Alloy | 0.1 " | 2.54 mm | Solder | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 3.18 mm | 0.125 in | Gold | Green | 2 | Non Specified - Dual Edge | 22 | Female | 44 | Dual | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Copper Alloy | 0.1 " | 2.54 mm | Wire Wrap | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 3.18 mm | 0.125 in | Gold | Green | 2 | Non Specified - Dual Edge | 22 | Female | 44 | Dual | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Copper Alloy | 0.1 " | 2.54 mm | Solder | Cantilever | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | 3.18 mm | 0.125 in | Gold | Green | Non Specified - Single Edge | 44 | Female | 44 | Single | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Copper Alloy | 0.1 " | 2.54 mm | Solder | Cantilever | 1 | 1 | 4-40 Flush Mount Threaded Insert Top Opening | ||||
EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | 3.18 mm | 0.125 in | Gold | Green | Non Specified - Single Edge | 44 | Female | 44 | Single | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Copper Alloy | 0.1 " | 2.54 mm | Wire Wrap | Cantilever | 1 | 1 | |||||
EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | 3.18 mm | 0.125 in | Gold | Green | 2 | Non Specified - Dual Edge | 22 | Female | 44 | Dual | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Copper Alloy | 0.1 " | 2.54 mm | Solder Eyelet(s) | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening |
