622-M37 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB RCPT 37POS R/A SOLDER
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Color | Dielectric Material | Contact Material | Termination | Number of Positions | Mounting Type | Current Rating (Amps) | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Shell Size, Connector Layout | Shell Size, Connector Layout | Number of Rows [custom] | Features | Connector Style | Flange Feature | Flange Feature | Material Flammability Rating | Connector Type | Shell Material, Finish | Contact Finish | Backset Spacing | Backset Spacing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -55 C | 125 °C | Green | Polyamide (PA6T) Nylon 6T | Copper Alloy | Solder | 37 | Board Edge Right Angle Through Hole | 5 A | Signal | 30 Áin | 0.76 Ám | 4 | DC C | 2 | Mounting Brackets Shielded | D-Sub | Housing/Shell | 4-40 | UL94 V-0 | Receptacle Female Sockets | Nickel Plated Steel | Gold | 7.2 mm | 0.283 in |
 EDAC Inc. | -55 C | 125 °C | Green | Polyamide (PA6T) Nylon 6T | Copper Alloy | Solder | 37 | Board Edge Right Angle Through Hole | 5 A | Signal | 15 µin | 0.38 µm | 4 | DC C | 2 | Board Lock Mounting Brackets Shielded | D-Sub | 4-40 | UL94 V-0 | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | ||
 EDAC Inc. | -55 C | 125 °C | White | Polyamide (PA6T) Nylon 6T | Copper Alloy | Solder | 37 | Board Edge Right Angle Through Hole | 5 A | Signal | 30 Áin | 0.76 Ám | 4 | DC C | 2 | Shielded | D-Sub | Housing/Shell | 4-40 | UL94 V-0 | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | |
 EDAC Inc. | -55 C | 125 °C | Green | Polyamide (PA6T) Nylon 6T | Copper Alloy | Solder | 37 | Board Edge Right Angle Through Hole | 5 A | Signal | 30 Áin | 0.76 Ám | 4 | DC C | 2 | Shielded | D-Sub | Housing/Shell | 4-40 | UL94 V-0 | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | |
 EDAC Inc. | -55 C | 125 °C | Black | Polyamide (PA6T) Nylon 6T | Copper Alloy | Solder | 37 | Board Edge Right Angle Through Hole | 5 A | Signal | 15 µin | 0.38 µm | 4 | DC C | 2 | Mounting Brackets Shielded | D-Sub | Housing/Shell | 4-40 | UL94 V-0 | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | |
 EDAC Inc. | -55 C | 125 °C | Blue | Polyamide (PA6T) Nylon 6T | Copper Alloy | Solder | 37 | Board Edge Right Angle Through Hole | 5 A | Signal | 30 Áin | 0.76 Ám | 4 | DC C | 2 | Mounting Brackets Shielded | D-Sub | Housing/Shell | 4-40 | UL94 V-0 | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | |
 EDAC Inc. | -55 C | 125 °C | White | Polyamide (PA6T) Nylon 6T | Copper Alloy | Solder | 37 | Board Edge Right Angle Through Hole | 5 A | Signal | 15 µin | 0.38 µm | 4 | DC C | 2 | Board Lock Mounting Brackets Shielded | D-Sub | Housing/Shell | 4-40 | UL94 V-0 | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | |
 EDAC Inc. | -55 C | 125 °C | Black | Polyamide (PA6T) Nylon 6T | Copper Alloy | Solder | 37 | Board Edge Right Angle Through Hole | 5 A | Signal | 30 Áin | 0.76 Ám | 4 | DC C | 2 | Mounting Brackets Shielded | D-Sub | 4-40 | UL94 V-0 | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | ||
 EDAC Inc. | -55 C | 125 °C | Blue | Polyamide (PA6T) Nylon 6T | Copper Alloy | Solder | 37 | Board Edge Right Angle Through Hole | 5 A | Signal | 15 µin | 0.38 µm | 4 | DC C | 2 | Shielded | D-Sub | Housing/Shell (Unthreaded) | UL94 V-0 | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | ||
 EDAC Inc. | -55 C | 125 °C | Blue | Polyamide (PA6T) Nylon 6T | Copper Alloy | Solder | 37 | Board Edge Right Angle Through Hole | 5 A | Signal | 15 µin | 0.38 µm | 4 | DC C | 2 | Board Lock Mounting Brackets Shielded | D-Sub | Housing/Shell | 4-40 | UL94 V-0 | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in |
