DKE10 Series

Catalog

DC DC CONVERTER +/-5V 10W

Part	Type	Current - Output (Max)	Number of Outputs	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Power (Watts)	Mounting Type	Voltage - Input (Max) [Max]	Applications	Package / Case	Voltage - Input (Min) [Min]	Features	Voltage - Output 1	Voltage - Output 2	Efficiency	Voltage - Isolation	Current - Output (Max)
MEAN WELL USA Inc. DKE10B-05	Isolated Module	1 A	2	-25 °C	71 °C	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	10 W	Through Hole	36 V	ITE (Commercial)	5-DIP Module	18 V	OCP SCP	5 V	-5 V	81 %	1000 V
MEAN WELL USA Inc. DKE10A-15	Isolated Module	333 mA	2	-25 °C	71 °C	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	10 W	Through Hole	18 V	ITE (Commercial)	5-DIP Module	9 V	OCP SCP	15 V	-15 V	80 %	1000 V
MEAN WELL USA Inc. DKE10C-12	Isolated Module	420 mA	2	-25 °C	71 °C	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	10 W	Through Hole	72 V	ITE (Commercial)	5-DIP Module	36 V	OCP SCP	12 V	-12 V	83 %	1000 V
MEAN WELL USA Inc. DKE10B-15	Isolated Module	333 mA	2	-25 °C	71 °C	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	10 W	Through Hole	36 V	ITE (Commercial)	5-DIP Module	18 V	OCP SCP	15 V	-15 V	80 %	1000 V
MEAN WELL USA Inc. DKE10A-05	Isolated Module	1 A	2	-25 °C	71 °C	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	10 W	Through Hole	18 V	ITE (Commercial)	5-DIP Module	9 V	OCP SCP	5 V	-5 V	78 %	1000 V
MEAN WELL USA Inc. DKE10B-12	Isolated Module	420 mA	2	-25 °C	71 °C	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	10 W	Through Hole	36 V	ITE (Commercial)	5-DIP Module	18 V	OCP SCP	12 V	-12 V	80 %	1000 V
MEAN WELL USA Inc. DKE10C-24	Isolated Module	210 mA	2	-25 °C	71 °C	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	10 W	Through Hole	72 V	ITE (Commercial)	5-DIP Module	36 V	OCP SCP	24 V	-24 V	85 %	1000 V	210 mA
MEAN WELL USA Inc. DKE10A-12	Isolated Module	420 mA	2	-25 °C	71 °C	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	10 W	Through Hole	18 V	ITE (Commercial)	5-DIP Module	9 V	OCP SCP	12 V	-12 V	80 %	1000 V
