SJ2-35 Series
Manufacturer: Same Sky (Formerly CUI Devices)
Beta
⌘K
AUDIO JACK, 3.5 MM, RT, 4 CONDUC
| Part | Mounting Type | Features | Connector Type | Number of Positions/Contacts [custom] | Number of Positions/Contacts [custom] | Actual Diameter [diameter] | Actual Diameter [diameter] | Gender | Termination | Signal Lines | Internal Switch(s) | Industry Recognized Mating Diameter | Industry Recognized Mating Diameter | Industry Recognized Mating Diameter | Operating Temperature [Max] | Operating Temperature [Min] | Shielding | Contact Material | Contact Material - Plating | Body Color | Voltage - Rated | Mating Length/Depth | Mating Length/Depth | Current Rating (Amps) | Internal Switch(s) | Housing Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Same Sky (Formerly CUI Devices) | Right Angle Surface Mount | Board Guide | Phone Jack | 4 | 4 | 0.142 in | 3.6 mm | Female | Solder | Stereo (4 Conductor TRRS) | 0.125 in | 3.5 mm | 0.141 in | 85 °C | -25 °C | Unshielded | ||||||||||
 Same Sky (Formerly CUI Devices) | Right Angle Surface Mount | Phone Jack | 3 | 4 | 0.142 in | 3.6 mm | Female | Solder | Stereo (3 Conductor TRS) | 0.125 in | 3.5 mm | 0.141 in | 85 °C | -25 °C | Unshielded | Brass Copper Alloy | Silver | Black | 12 VDC | 14 mm | 0.551 in | 1 A | Single Switch | Polyamide (PA10T) Nylon 10T | ||
 Same Sky (Formerly CUI Devices) | Right Angle Surface Mount | Board Guide | Phone Jack | 4 | 5 | 0.142 in | 3.6 mm | Female | Solder | Stereo (4 Conductor TRRS) | 0.125 in | 3.5 mm | 0.141 in | 85 °C | -25 °C | Unshielded | Copper Alloy | Silver | Black | 12 VDC | 14 mm | 0.551 in | 1 A | Single Switch | Polyamide (PA10T) Nylon 10T | |
 Same Sky (Formerly CUI Devices) | Right Angle Surface Mount | Board Guide | Phone Jack | 3 | 3 | 0.142 in | 3.6 mm | Female | Solder | Stereo (3 Conductor TRS) | 0.125 in | 3.5 mm | 0.141 in | 85 °C | -25 °C | Unshielded | Copper Alloy | Silver | Black | 12 VDC | 14 mm | 0.551 in | 1 A | Polyamide (PA10T) Nylon 10T | ||
 Same Sky (Formerly CUI Devices) | Right Angle Surface Mount | Phone Jack | 4 | 5 | 0.142 in | 3.6 mm | Female | Solder | Stereo (4 Conductor TRRS) | 0.125 in | 3.5 mm | 0.141 in | 85 °C | -25 °C | Unshielded | Copper Alloy | Silver | Black | 12 VDC | 14 mm | 0.551 in | 1 A | Single Switch | Polyamide (PA10T) Nylon 10T | ||
 Same Sky (Formerly CUI Devices) | Right Angle Surface Mount | Phone Jack | 5 | 5 | 0.142 in | 3.6 mm | Female | Solder | 5 Conductor (TRRRS) | 0.125 in | 3.5 mm | 0.141 in | 85 °C | -25 °C | Unshielded | Copper Alloy | Gold | Black | 12 VDC | 14 mm | 0.551 in | 1 A | Polyamide (PA10T) Nylon 10T | |||
 Same Sky (Formerly CUI Devices) | Right Angle Surface Mount | Board Guide | Phone Jack | 4 | 4 | 0.142 in | 3.6 mm | Female | Solder | Stereo (4 Conductor TRRS) | 0.125 in | 3.5 mm | 0.141 in | 85 °C | -25 °C | |||||||||||
 Same Sky (Formerly CUI Devices) | Right Angle Surface Mount | Board Guide | Phone Jack | 3 | 5 | 0.142 in | 3.6 mm | Female | Solder | Stereo (3 Conductor TRS) | 0.125 in | 3.5 mm | 0.141 in | 85 °C | -25 °C | Unshielded | Brass Copper Alloy | Gold | Black | 12 VDC | 14 mm | 0.551 in | 1 A | Two Switches | Polyamide (PA10T) Nylon 10T | |
 Same Sky (Formerly CUI Devices) | Right Angle Surface Mount | Board Guide | Phone Jack | 4 | 4 | 0.142 in | 3.6 mm | Female | Solder | Stereo (4 Conductor TRRS) | 0.125 in | 3.5 mm | 0.141 in | 85 °C | -25 °C | Unshielded | Copper Alloy | Copper Alloy | Black | 12 VDC | 14 mm | 0.551 in | 1 A | Polyamide (PA10T) Nylon 10T | ||
Same Sky (Formerly CUI Devices) | Right Angle Surface Mount | Board Guide | Phone Jack | 4 | 5 | 0.142 in | 3.6 mm | Female | Solder | Stereo (4 Conductor TRRS) | 0.125 in | 3.5 mm | 0.141 in | 85 °C | -25 °C | Unshielded | Single Switch |
