1415356 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RELAY GEN PURPOSE SPST 6A 5V
| Part | Coil Resistance | Must Release Voltage | Seal Rating | Contact Material | Coil Voltage | Operate Time | Must Operate Voltage | Approval Agency | Contact Rating (Current) | Switching Voltage [Max] | Relay Type | Coil Type | Release Time | Coil Current | Termination Style | Load - Max Switching | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Contact Form | Coil Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 70 Ohms | 0.5 VDC | Sealed - Flux Protection | Silver Nickel (AgNi) | 5 VDC | 10 ms | 3.75 VDC | cURus VDE | 6 A | 400 VAC | General Purpose | Non Latching | 20 ms | 71.4 mA | PC Pin | 2400 VA | -20 ░C | 105 ░C | Through Hole | SPST-NO (1 Form A) | |
 TE Connectivity AMP Connectors | 100 Ohms | 0.6 VDC | Silver Nickel (AgNi) | 10 ms | 4.5 VDC | cURus VDE | 6 A | 400 VAC | General Purpose | Non Latching | 20 ms | 0.06 A | PC Pin | 2400 VA | -20 ░C | 105 ░C | Through Hole | SPDT (1 Form C) | Class F |
