SMS6SE Series

Catalog

CONN RCPT 6POS 0.2 GOLD PCB R/A

Part	Contact Shape	Insulation Material	Contact Material	Contact Finish Thickness - Mating	Material Flammability Rating	Operating Temperature (Min)	Operating Temperature (Max)	Ingress Protection	Termination	Contact Finish - Post	Current Rating	Mounting Type	Style	Contact Finish - Mating	Number of Rows	Pitch - Mating	Insulation Color	Fastening Type	Number of Positions	Row Spacing - Mating	Number of Positions Loaded	Contact Type	Connector Type	Features	Contact Length - Post	Insulation Height
Amphenol Aerospace Operations SMS6SE5K9	Circular	Glass Filled Thermoplastic	Copper Alloy	16 µin	UL94 V-0	-55 °C	105 °C	IP40	Solder	Tin	5 A	Right Angle Through Hole	Board Board or Cable	Gold	2	0.2 in	Black	Locking Ramp	6	0.2 in	All	Female Socket	Receptacle	Mounting Flange	0.177 in
Amphenol Aerospace Operations SMS6SE3K9	Circular	Glass Filled Thermoplastic	Copper Alloy	16 µin	UL94 V-0	-55 °C	105 °C	IP40	Solder	Tin	5 A	Through Hole	Board Board or Cable	Gold	2	0.2 in	Black	Locking Ramp	6	0.2 in	All	Female Socket	Receptacle	Mounting Flange	0.134 in	0.528 in
