Reed Relays HV RELAYS
Reed Relays HV RELAYS
| Part | Mounting Type | Contact Material | Coil Voltage | Coil Current | Contact Form | Contact Rating (Current) | Must Release Voltage | Must Operate Voltage | Termination Style | Coil Type | Operating Temperature [Min] | Operating Temperature [Max] | Switching Voltage [Max] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | Through Hole | Tungsten (W) | 12 VDC | 35.3 mA | SPDT (1 Form C) | 3 A | 1.2 VDC | 9 VDC | PC Pin | Non Latching | -40 C | 65 °C | 240 VDC | |
 Sensata-Crydom | Through Hole | Tungsten (W) | 5 VDC | 0.1 A | SPDT (1 Form C) | 3 A | 0.5 VDC | 3.75 VDC | PC Pin | Non Latching | -40 C | 65 °C | 240 VDC | EMI Shielded |
 Sensata-Crydom | Through Hole | Tungsten (W) | 12 VDC | 35.3 mA | SPDT (1 Form C) | 3 A | 1.2 VDC | 9 VDC | PC Pin | Non Latching | -40 C | 65 °C | 240 VDC | EMI Shielded |
Sensata-Crydom | Through Hole | Tungsten (W) | 5 VDC | 0.1 A | SPDT (1 Form C) | 3 A | 0.5 VDC | 3.75 VDC | PC Pin | Non Latching | -40 C | 65 °C | 240 VDC | |
 Sensata-Crydom | Through Hole | Tungsten (W) | 24 VDC | 26.7 mA | SPDT (1 Form C) | 3 A | 2.4 VDC | 18 VDC | PC Pin | Non Latching | -40 C | 65 °C | 240 VDC | |
Sensata-Crydom | Through Hole | Tungsten (W) | 24 VDC | 26.7 mA | SPDT (1 Form C) | 3 A | 2.4 VDC | 18 VDC | PC Pin | Non Latching | -40 C | 65 °C | 240 VDC | EMI Shielded |
