EPM6xx2V Series
Isolated DC/DC Converters - SMD EPM6 1W 24Vin 5Vout 200mA 3kV
Manufacturer: Eaton - Electronics Division
Catalog
Isolated DC/DC Converters - SMD EPM6 1W 24Vin 5Vout 200mA 3kV
Beta
⌘K
Isolated DC/DC Converters - SMD EPM6 1W 24Vin 5Vout 200mA 3kV
Isolated DC/DC Converters - SMD EPM6 1W 24Vin 5Vout 200mA 3kV
Isolated DC/DC Converters - SMD EPM6 1W 24Vin 5Vout 200mA 3kV
| Part | Standard Number | Voltage - Input (Max) [Max] | Voltage - Output 1 | Package / Case | Voltage - Input (Min) [Min] | Type | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Number of Outputs | Current - Output (Max) [Max] | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Isolation | Mounting Type | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Eaton - Electronics Division | 62368-1 | 13.2 V | 5 V | 7-DIP Module 4 Leads | 10.8 V | Isolated Module | 0.24 " | 0.4 " | 19.7 mm | 10.2 mm | 0.77 in | 6 mm | 1 | 200 mA | ITE (Commercial) | -40 °C | 100 °C | 3000 V | Through Hole | |
Eaton - Electronics Division | 62368-1 | 26.4 V | 5 V | 7-DIP Module 4 Leads | 21.6 V | Isolated Module | 0.24 " | 0.4 " | 19.7 mm | 10.2 mm | 0.77 in | 6 mm | 1 | 200 mA | ITE (Commercial) | -40 °C | 100 °C | 3000 V | Through Hole | 79 % |
