PMF-24 Series
Manufacturer: Delta Electronics
Beta
⌘K
AC/DC CONVERTER 24V 200W
| Part | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Voltage - Isolation | Voltage - Output 1 | Current - Output 1 | Efficiency | Number of Outputs | Type | Power (Watts) | Approval Agency | Features | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Mounting Type | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delta Electronics | 93 mm | 1.97 in | 7.48 " | 190 mm | 3.66 " | 50 mm | 3000 V | 24 V | 8.4 A | 87 % | 1 | Enclosed | 200 Watts | CB CCC CE cURus TUVgs | Adjustable Output PFC Remote On/Off Universal Input | 70 °C | -10 °C | ITE (Commercial) | Chassis Mount | |||
 Delta Electronics | 93 mm | 1.97 in | 7.48 " | 190 mm | 3.66 " | 50 mm | 3000 V | 24 V | 8.4 A | 87 % | 1 | Enclosed | 200 Watts | CB CCC CE cURus TUVgs | Adjustable Output PFC Universal Input | 70 °C | -10 °C | ITE (Commercial) | Chassis Mount | |||
 Delta Electronics | 115 mm | 215 mm | 50 mm | 3000 V | 24 V | 13.3 A | 87 % | 1 | Enclosed | 320 W | CB CCC CE cURus TUVgs | Adjustable Output PFC Universal Input | 70 °C | -10 °C | ITE (Commercial) | Chassis Mount | 8.46 in | 4.53 in | 1.97 " | |||
 Delta Electronics | 93 mm | 1.97 in | 7.48 " | 190 mm | 3.66 " | 50 mm | 3000 V | 24 V | 8.4 A | 87 % | 1 | Enclosed | 200 Watts | CB CCC CE cURus TUVgs | Adjustable Output PFC Universal Input | 70 °C | -10 °C | ITE (Commercial) | Chassis Mount | |||
 Delta Electronics | 93 mm | 1.97 in | 7.48 " | 190 mm | 3.66 " | 50 mm | 3000 V | 24 V | 10 A | 87 % | 1 | Enclosed | 240 Watts | CB CCC CE cURus TUVgs | Adjustable Output PFC Remote On/Off Universal Input | 70 °C | -10 °C | ITE (Commercial) | Chassis Mount |
