641H Series
Manufacturer: APEM Inc.
Beta
⌘K
SWITCH TOGGLE DPST 15A 250V
| Part | Electrical Life | Actuator Material | Illumination | Actuator Length [x] | Current Rating (Amps) | Voltage Rating - AC | Panel Cutout Dimensions [diameter] | Bushing Thread | Switch Function | Operating Temperature [Max] | Operating Temperature [Min] | Termination Style | Mounting Type | Features | Circuit | Actuator Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 APEM Inc. | 10000 Cycles | Brass Nickel Plated | Non-Illuminated | 17.5 mm | 15 A | 250 V | 12.2 mm Dia | M12 x 0.75 | On-Off | 55 °C | -20 ░C | Quick Connect - 0.250" (6.3mm) | Panel Mount | Front Panel Sealing | DPST | Standard Round |
 APEM Inc. | 10000 Cycles | Brass Nickel Plated | Non-Illuminated | 19.4 mm | 15 A | 250 V | 12.2 mm Dia | 15/32-32 | On-Off | 55 °C | -20 ░C | Quick Connect - 0.250" (6.3mm) | Panel Mount | DPST | Locking Lever |
