Isolated DC/DC Converters - Through Hole
Isolated DC/DC Converters - Through Hole
| Part | Applications | Voltage - Isolation | Approval Agency | Type | Efficiency | Features | Voltage - Output 1 | Mounting Type | Voltage - Input (Max) [Max] | Current - Output (Max) [Max] | Power (Watts) | Control Features | Number of Outputs | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Input (Min) [Min] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Standard Number | Current - Output (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cincon Electronics Co. LTD | ITE (Commercial) | 1.5 kV | CE cURus | Isolated Module | 84 % | OCP OTP OVP Remote On/Off SCP UVLO | 5 V | Through Hole | 36 V | 12 A | 60 W | Active Low Enable | 1 | Module | -40 °C | 100 °C | 9 V | 57.9 mm | 1.45 in | 0.5 in | 2.28 " | 12.7 mm | 36.8 mm | 60950-1 | |
Cincon Electronics Co. LTD | ITE (Commercial) | 1.5 kV | CE cURus | Isolated Module | 86 % | OCP OTP OVP Remote On/Off SCP UVLO | 15 V | Through Hole | 36 V | 75 W | Active Low Enable | 1 | Module | -40 °C | 100 °C | 9 V | 57.9 mm | 1.45 in | 0.5 in | 2.28 " | 12.7 mm | 36.8 mm | 60950-1 | 5 A | |
 Cincon Electronics Co. LTD | ITE (Commercial) | 1.5 kV | CE cURus | Isolated Module | 81 % | OCP OTP OVP Remote On/Off SCP UVLO | 3.3 V | Through Hole | 36 V | 12 A | 40 W | Active High Enable | 1 | Module | -40 °C | 100 °C | 9 V | 57.9 mm | 1.45 in | 0.5 in | 2.28 " | 12.7 mm | 36.8 mm | 60950-1 |
