396-072 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 72POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Read Out | Card Type | Termination | Features | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Color | Pitch | Pitch | Contact Finish | Flange Feature | Mounting Type | Number of Positions/Bay/Row | Gender | Contact Type | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Solder Wire Wrap | Card Guides | 0.25 Ám | 10 Áin | 72 | Black | 3.18 mm | 0.125 in | Gold | 4-40 Threaded Insert Top Mount Opening | Right Angle Through Hole | 36 | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 2 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Solder | Card Extender | 0.25 Ám | 10 Áin | 72 | Black | 3.18 mm | 0.125 in | Gold | M3 Threaded Insert Top Mount Opening | Board Edge Straddle Mount | 36 | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 2 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Solder Eyelet(s) | Card Extender | 0.25 Ám | 10 Áin | 72 | Black | 3.18 mm | 0.125 in | Gold | Flush Mount Side Opening Unthreaded | Board Edge Straddle Mount | 36 | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 2 | 0.128 " | 3.25 mm |
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Solder | Card Extender Card Guides | 0.25 Ám | 10 Áin | 72 | Black | 3.18 mm | 0.125 in | Gold | 4-40 Threaded Insert Top Mount Opening | Board Edge Straddle Mount | 36 | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 2 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Solder Wire Wrap | 0.25 Ám | 10 Áin | 72 | Black | 3.18 mm | 0.125 in | Gold | Side Mount Opening Unthreaded | Right Angle Through Hole | 36 | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 2 | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Solder Eyelet(s) | Card Extender | 0.25 Ám | 10 Áin | 72 | Black | 3.18 mm | 0.125 in | Gold | 4-40 Threaded Insert Top Mount Opening | Board Edge Straddle Mount | 36 | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 2 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Solder | Card Extender Card Guides | 0.25 Ám | 10 Áin | 72 | Black | 3.18 mm | 0.125 in | Gold | 4-40 Threaded Insert Top Mount Opening | Board Edge Straddle Mount | 36 | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 2 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Solder | Card Guides | 0.25 Ám | 10 Áin | 72 | Black | 3.18 mm | 0.125 in | Gold | 4-40 Threaded Insert Top Mount Opening | Through Hole | 36 | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 2 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Solder | 0.25 Ám | 10 Áin | 72 | Black | 3.18 mm | 0.125 in | Gold | Flush Mount Top Opening Unthreaded | Through Hole | 36 | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 2 | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Solder Wire Wrap | 0.25 Ám | 10 Áin | 72 | Black | 3.18 mm | 0.125 in | Gold | Right Angle Through Hole | 36 | Female | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | 2 |
