8ETX06 Series

Manufacturer: Vishay General Semiconductor - Diodes Division

Catalog

DIODE GEN PURP 600V 8A TO220AC

Part	Current - Average Rectified (Io)	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Mounting Type	Voltage - Forward (Vf) (Max) @ If	Package / Case	Current - Reverse Leakage @ Vr	Voltage - DC Reverse (Vr) (Max) [Max]	Speed	Technology	Supplier Device Package	Reverse Recovery Time (trr)	Grade	Qualification
Vishay General Semiconductor - Diodes Division 8ETX06	8 A	175 ░C	-65 C	Through Hole	3 V	TO-220-2	50 µA	600 V	200 mA 500 ns	Standard	TO-220AC	24 ns
Vishay General Semiconductor - Diodes Division VS-8ETX06FP-N3	8 A	175 ░C	-65 C	Through Hole	3 V	TO-220-2 Full Pack	50 µA	600 V	200 mA 500 ns	Standard	TO-220-2 Full Pack	17 ns
Vishay General Semiconductor - Diodes Division VS-8ETX06FPPBF	8 A	175 ░C	-65 C	Through Hole	3 V	TO-220-2 Full Pack	50 µA	600 V	200 mA 500 ns	Standard	TO-220-2 Full Pack	24 ns
Vishay General Semiconductor - Diodes Division VS-8ETX06STRRPBF	8 A	175 ░C	-65 C	Surface Mount	3 V	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	50 µA	600 V	200 mA 500 ns	Standard	TO-263AB (D2PAK)	17 ns	Automotive	AEC-Q101
Vishay General Semiconductor - Diodes Division VS-8ETX06SPBF	8 A	175 ░C	-65 C	Surface Mount	3 V	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	50 µA	600 V	200 mA 500 ns	Standard	TO-263AB (D2PAK)	17 ns
Vishay General Semiconductor - Diodes Division VS-8ETX06S-M3	8 A	175 ░C	-65 C	Surface Mount	3 V	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	50 µA	600 V	200 mA 500 ns	Standard	TO-263AB (D2PAK)	24 ns
Vishay General Semiconductor - Diodes Division 8ETX06FP	8 A	175 ░C	-65 C	Through Hole	3 V	TO-220-2 Full Pack	50 µA	600 V	200 mA 500 ns	Standard	TO-220AC Full Pack	24 ns
Vishay General Semiconductor - Diodes Division VS-8ETX06-M3	8 A	175 ░C	-65 C	Through Hole	3 V	TO-220-2	50 µA	600 V	200 mA 500 ns	Standard	TO-220AC	24 ns
Vishay General Semiconductor - Diodes Division VS-8ETX06-1PBF	8 A	175 ░C	-65 C	Through Hole	3 V	I2PAK TO-262-3 Long Leads TO-262AA	50 µA	600 V	200 mA 500 ns	Standard	TO-262-3	24 ns
Vishay General Semiconductor - Diodes Division VS-8ETX06STRR-M3	8 A	175 ░C	-65 C	Surface Mount	3 V	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	50 µA	600 V	200 mA 500 ns	Standard	TO-263AB (D2PAK)	24 ns
