28348 Series
Manufacturer: Phoenix Contact
Beta
⌘K
RELAY GEN PURPOSE SPDT 16A 48V
| Part | Coil Resistance | Contact Rating (Current) | Mounting Type | Switching Voltage | Termination Style | Release Time | Operate Time | Contact Material | Coil Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Coil Current | Relay Type | Contact Form | Coil Type | Approval Agency | Load - Max Switching [Max] | Switching Voltage [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 5.52 kOhms | 16 A | Through Hole | 250 VAC 250 VDC | PC Pin | 3 ms | 7 ms | Silver Nickel (AgNi) | 48 VDC | 85 °C | -40 C | 8.7 mA | General Purpose | SPDT (1 Form C) | Non Latching | cULus EAC UR | ||
 Phoenix Contact | 5.52 kOhms | 8 A | Through Hole | 250 VAC 250 VDC | PC Pin | 3 ms | 7 ms | Silver Nickel (AgNi) | 48 VDC | 85 °C | -40 C | 8.7 mA | General Purpose | DPDT (2 Form C) | Non Latching | |||
 Phoenix Contact | 5.52 kOhms | 8 A | Through Hole | PC Pin | 3 ms | 7 ms | Gold (Au) Silver Nickel (AgNi) | 48 VDC | 85 °C | -40 C | 8.7 mA | General Purpose | DPDT (2 Form C) | Non Latching | cULus EAC UR | 2000 VA | 250 VAC |
