392-102 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 102POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Read Out | Termination | Number of Positions/Bay/Row [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Contact Type | Pitch | Pitch | Number of Positions | Mounting Type | Color | Number of Rows [custom] | Card Type | Gender | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Dual | Wire Wrap | 51 | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 102 | Through Hole | Black | 2 | Non Specified - Dual Edge | Female | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Dual | Wire Wrap | 51 | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 102 | Through Hole | Black | 2 | Non Specified - Dual Edge | Female | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 0.25 Ám | 10 Áin | Dual | Solder | 51 | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 102 | Through Hole | Black | 2 | Non Specified - Dual Edge | Female | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Dual | Solder Eyelet(s) | 51 | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 102 | Board Edge Straddle Mount | Black | 2 | Non Specified - Dual Edge | Female | Card Extender |
 EDAC Inc. | Polyester Thermoplastic | 2 | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 0.25 Ám | 10 Áin | Dual | Wire Wrap | 51 | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 102 | Through Hole | Black | 2 | Non Specified - Dual Edge | Female | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Dual | Wire Wrap | 51 | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 102 | Through Hole | Black | 2 | Non Specified - Dual Edge | Female | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Dual | Solder Wire Wrap | 51 | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 102 | Right Angle Through Hole | Black | 2 | Non Specified - Dual Edge | Female | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Dual | Solder | 51 | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 102 | Through Hole | Black | 2 | Non Specified - Dual Edge | Female | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 0.25 Ám | 10 Áin | Dual | Wire Wrap | 51 | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 102 | Through Hole | Black | 2 | Non Specified - Dual Edge | Female | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Dual | Wire Wrap | 51 | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | 102 | Through Hole | Black | 2 | Non Specified - Dual Edge | Female |
