GRS-2013 Series
Manufacturer: CW Industries
Beta
⌘K
SWITCH ROCKER SPDT 13A 125V
| Part | Mounting Type | Switch Function | Actuator Type | Circuit | Color - Actuator/Cap | Features | Current Rating (Amps) | Actuator Marking | Termination Style | Voltage Rating - AC | Operating Temperature [Min] | Operating Temperature [Max] | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Mechanical Life | Electrical Life |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CW Industries | Panel Mount Snap-In | Mom-Off-Mom | Concave (Curved) | SPDT | White | Terminal Barriers | 13 A | No Marking | Quick Connect - 0.250" (6.3mm) | 125 V | -20 ░C | 105 ░C | 13.97 mm | 28.58 mm | ||
 CW Industries | Panel Mount Snap-In | On-Off-On | Concave (Curved) | SPDT | Black | Polarized | 16 A | No Marking | Quick Connect - 0.250" (6.3mm) | 125 V | -20 ░C | 105 ░C | 12.19 mm | 27.23 mm | 25000 Steps | 25000 Steps |
 CW Industries | Panel Mount Snap-In | Mom-Off-Mom | Concave (Curved) | SPDT | Black | 13 A | No Marking | Quick Connect - 0.250" (6.3mm) | 125 V | -20 ░C | 105 ░C | 13.97 mm | 28.58 mm | 100000 Cycles | 25000 Steps | |
 CW Industries | Panel Mount Snap-In | On-Off-On | Concave (Curved) | SPDT | Brown | 16 A | No Marking | Quick Connect - 0.250" (6.3mm) | 125 V | -20 ░C | 105 ░C | 13.97 mm | 28.58 mm | 25000 Steps | 25000 Steps | |
 CW Industries | Panel Mount Snap-In | On-Off-Mom | Concave (Curved) | SPDT | Black | 13 A | No Marking | Quick Connect - 0.250" (6.3mm) | 125 V | -20 ░C | 105 ░C | 13.97 mm | 28.58 mm | 25000 Steps | 25000 Steps | |
 CW Industries | Panel Mount Snap-In | On-Off-On | Concave (Curved) | SPDT | Black | 8 A | No Marking | Quick Connect - 0.250" (6.3mm) | 125 V | -20 ░C | 105 ░C | 12.19 mm | 27.23 mm | 25000 Steps | 25000 Steps | |
 CW Industries | Panel Mount Snap-In | On-Off-On | Concave (Curved) | SPDT | Black | 16 A | No Marking | Quick Connect - 0.250" (6.3mm) | 125 V | -20 ░C | 105 ░C | 12.19 mm | 27.23 mm | 25000 Steps | 25000 Steps | |
 CW Industries | Panel Mount Snap-In | On-Off-On | Concave (Curved) | SPDT | Black | Polarized Terminal Barriers | 16 A | No Marking | Quick Connect - 0.250" (6.3mm) | 125 V | -20 ░C | 105 ░C | 12.19 mm | 27.23 mm | 25000 Steps | 25000 Steps |
 CW Industries | Panel Mount Snap-In | On-Off-On | Concave (Curved) | SPDT | Black | 16 A | No Marking | Quick Connect - 0.250" (6.3mm) | 125 V | -20 ░C | 105 ░C | 13.97 mm | 28.58 mm | 100000 Cycles | 25000 Steps | |
 CW Industries | Panel Mount Snap-In | On-Off-Mom | Concave (Curved) | SPDT | Black | 8 A | No Marking | Quick Connect - 0.250" (6.3mm) | 125 V | -20 ░C | 105 ░C | 13.97 mm | 28.58 mm | 25000 Steps | 25000 Steps |
