HPC 252010BMV Series

Catalog

FIXED IND 1UH 2.4A 0.072OHM SMD

Part	Operating Temperature [Min]	Operating Temperature [Max]	DC Resistance (DCR)	Supplier Device Package	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Type	Inductance Frequency - Test	Shielding	Mounting Type	Current - Saturation (Isat)	Inductance	Package / Case	Package / Case	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Current Rating (Amps)	Ratings	Material - Core	DC Resistance (DCR) [Max]
TAI-TECH Advanced Electronics Co., Ltd. HPC 252010BMV-1R0M	-55 C	125 °C	72 mOhm	252010	2.5 mm	0.079 in	0.098 in	2 mm	Wirewound	100 kHz	Shielded	Surface Mount	2.3 A	1 µH	2520 Metric	1008	20 %	0.039 in	1 mm	2.4 A	AEC-Q200	Ferrite
TAI-TECH Advanced Electronics Co., Ltd. HPC 252010BMV-4R7M	-55 C	125 °C		252010	2.5 mm	0.079 in	0.098 in	2 mm	Wirewound	100 kHz	Shielded	Surface Mount	1.1 A	4.7 ÁH	2520 Metric	1008	20 %	0.039 in	1 mm	1.2 A	AEC-Q200	Ferrite	300 mOhm
TAI-TECH Advanced Electronics Co., Ltd. HPC 252010BMV-2R2M	-55 C	125 °C		252010	2.5 mm	0.079 in	0.098 in	2 mm	Wirewound	100 kHz	Shielded	Surface Mount	1.3 A	2.2 µH	2520 Metric	1008	20 %	0.039 in	1 mm	1.8 A	AEC-Q200	Ferrite	132 mOhm
TAI-TECH Advanced Electronics Co., Ltd. HPC 252010BMV-100M	-55 C	125 °C	552 mOhm	252010	2.5 mm	0.079 in	0.098 in	2 mm	Wirewound	100 kHz	Shielded	Surface Mount	0.65 A	10 µH	2520 Metric	1008	20 %	0.039 in	1 mm	800 mA	AEC-Q200	Ferrite
