1971921 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER VERT 9POS 2.5MM
| Part | Pitch - Mating | Pitch - Mating | Contact Material | Connector Type | Insulation Height | Insulation Height | Number of Positions Loaded [custom] | Contact Shape | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Color | Shrouding | Features | Mounting Type | Material Flammability Rating | Number of Positions | Fastening Type | Termination | Applications | Contact Length - Post | Contact Length - Post | Insulation Material | Number of Rows | Contact Type | Style | Contact Finish - Post | Number of Positions Loaded |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | 2.5 mm | 0.098 in | Copper Alloy | Header | 0.61 in | 15.49 mm | 5 | Rectangular | -40 °C | 120 °C | Natural | Shrouded - 4 Wall | Board Guide Glow Wire Compliant | Through Hole | UL94 V-0 | 9 | Locking Ramp | Solder | General Purpose | 0.114 in | 2.9 mm | Nylon Polyamide (PA) | 1 | Tab | Board to Cable/Wire | Tin | |
 TE Connectivity Raychem Cable Protection | 2.5 mm | 0.098 in | Copper Alloy | Header | 0.61 in | 15.49 mm | Rectangular | -40 °C | 120 °C | Natural | Shrouded - 4 Wall | Board Guide Glow Wire Compliant | Through Hole | UL94 V-0 | Locking Ramp | Solder | General Purpose | 0.114 in | 2.9 mm | Nylon Polyamide (PA) | 1 | Tab | Board to Cable/Wire | Tin | 3 | ||
 TE Connectivity Raychem Cable Protection | 2.5 mm | 0.098 in | Copper Alloy | Header | 0.61 in | 15.49 mm | Rectangular | -40 °C | 120 °C | Natural | Shrouded - 4 Wall | Board Guide Glow Wire Compliant | Through Hole | UL94 V-0 | Locking Ramp | Solder | General Purpose | 0.114 in | 2.9 mm | Nylon Polyamide (PA) | 1 | Tab | Board to Cable/Wire | Tin | 3 | ||
 TE Connectivity Raychem Cable Protection | 2.5 mm | 0.098 in | Copper Alloy | Header | 0.61 in | 15.49 mm | Rectangular | -40 °C | 120 °C | Natural | Shrouded - 4 Wall | Board Guide Glow Wire Compliant | Through Hole | UL94 V-0 | Locking Ramp | Solder | General Purpose | 0.114 in | 2.9 mm | Nylon Polyamide (PA) | 1 | Tab | Board to Cable/Wire | Tin | 2 | ||
 TE Connectivity Raychem Cable Protection | 2.5 mm | 0.098 in | Copper Alloy | Header | 0.61 in | 15.49 mm | Rectangular | -40 °C | 120 °C | Natural | Shrouded - 4 Wall | Board Guide Glow Wire Compliant | Through Hole | UL94 V-0 | Locking Ramp | Solder | General Purpose | 0.114 in | 2.9 mm | Nylon Polyamide (PA) | 1 | Tab | Board to Cable/Wire | Tin | 2 |
