2M Series
Manufacturer: Carling Technologies
Beta
⌘K
TOGGLE SWITCHES 2M1SP4T7B0M2QE
| Part | Current Rating (Amps) | Switch Function | Voltage Rating - AC | Panel Cutout Dimensions [diameter] | Voltage Rating - DC | Ingress Protection | Actuator Type | Features | Actuator Length [x] | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Illumination | Termination Style | Bushing Thread | Circuit | Accessory Type | For Use With/Related Products | Switch Type | Shape | Color | Electrical Life | Actuator Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Carling Technologies | 5 A | Mom-Off-Mom | 125 V | 11.91 mm | 28 V | IP67 - Dust Tight Waterproof | Anti-Rotation | Epoxy Sealed Terminals | 11.68 mm | 85 °C | -30 ░C | Panel Mount | Non-Illuminated | PC Pin | 15/32-32 | SPDT | |||||||
Carling Technologies | Locking Ring | 2M Series | |||||||||||||||||||||
Carling Technologies | 0.4 VA | On-On | 20 V | 0.25 in | 20 V | IP67 - Dust Tight Waterproof | Standard Round | Epoxy Sealed Terminals | 10.69 mm | 85 °C | -30 ░C | Panel Mount | Non-Illuminated | Solder Lug | 1/4-40 | SPDT | |||||||
 Carling Technologies | 5 A | On-Off-On | 125 V | 0.25 in | 28 V | IP67 - Dust Tight Waterproof | Standard Round | Epoxy Sealed Terminals | 10.4 mm | 85 °C | -30 ░C | Panel Mount | Non-Illuminated | Solder Lug | 1/4-40 | SPDT | |||||||
 Carling Technologies | Snap Fit | Non-Illuminated | 2M Series | Toggle | Bat | Red | |||||||||||||||||
Carling Technologies | 5 A | On-On | 125 V | 0.25 in | 28 V | IP67 - Dust Tight Waterproof | Standard Round | Epoxy Sealed Terminals | 18.01 mm | 85 °C | -30 ░C | Panel Mount | Non-Illuminated | Solder Lug | 1/4-40 | SPDT | |||||||
Carling Technologies | 5 A | Mom-Off-Mom | 125 V | 0.25 in | 28 V | IP67 - Dust Tight Waterproof | Flatted | Epoxy Sealed Terminals | 12.1 mm | 85 °C | -30 ░C | Panel Mount | Non-Illuminated | Solder Lug | 1/4-40 | SPDT | |||||||
Carling Technologies | 5 A | On-Mom | 125 V | 0.25 in | 28 V | IP67 - Dust Tight Waterproof | Standard Round | Epoxy Sealed Terminals | 10.39 mm | 85 °C | -30 ░C | Panel Mount | Non-Illuminated | Quick Connect - 0.062" (1.5mm) | 1/4-40 | DPDT | 50000 Cycles | Brass Chrome Plated | |||||
 Carling Technologies | 5 A | On-Off-Mom | 125 V | 0.25 in | 28 V | IP67 - Dust Tight Waterproof | Standard Round | Epoxy Sealed Terminals | 10.4 mm | 85 °C | -30 ░C | Panel Mount | Non-Illuminated | Solder Lug | 1/4-40 | SPDT | 50000 Cycles | Brass Chrome Plated | |||||
Carling Technologies | 5 A | Mom-Off-Mom | 125 V | 0.25 in | 28 V | IP67 - Dust Tight Waterproof | Standard Round | Epoxy Sealed Terminals | 5.41 mm | 85 °C | -30 ░C | Panel Mount | Non-Illuminated | PC Pin | 1/4-40 | SPDT |
