837-030 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 30POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Termination | Gender | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Contact Type | Card Type | Pitch | Pitch | Number of Rows [custom] | Number of Positions | Read Out | Mounting Type | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Color | Contact Material | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 15 | 0.25 Ám | 10 Áin | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Cantilever | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | 30 | Dual | Through Hole | Gold | 125 °C | -40 C | Green | Copper Alloy | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | 0.25 Ám | 10 Áin | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | Cantilever | Non Specified - Single Edge | 3.96 mm | 0.156 in | 30 | Single | Through Hole | Gold | 125 °C | -40 C | Green | Copper Alloy | 1 | 1 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 15 | 0.25 Ám | 10 Áin | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | Cantilever | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | 30 | Dual | Through Hole | Gold | 125 °C | -40 C | Green | Copper Alloy | 0.116 " | 2.95 mm | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 15 | 0.25 Ám | 10 Áin | Wire Wrap | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | Cantilever | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | 30 | Dual | Through Hole | Gold | 125 °C | -40 C | Green | Copper Alloy | 0.116 " | 2.95 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | 0.25 Ám | 10 Áin | Wire Wrap | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Non Specified - Single Edge | 3.96 mm | 0.156 in | 30 | Single | Through Hole | Gold | 125 °C | -40 C | Green | Copper Alloy | 1 | 1 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | 0.25 Ám | 10 Áin | Wire Wrap | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | Cantilever | Non Specified - Single Edge | 3.96 mm | 0.156 in | 30 | Single | Through Hole | Gold | 125 °C | -40 C | Green | Copper Alloy | 1 | 1 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | 0.25 Ám | 10 Áin | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | Cantilever | Non Specified - Single Edge | 3.96 mm | 0.156 in | 30 | Single | Right Angle Through Hole | Gold | 125 °C | -40 C | Green | Copper Alloy | 1 | 1 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 15 | 0.25 Ám | 10 Áin | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | Cantilever | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | 30 | Dual | Through Hole | Gold | 125 °C | -40 C | Green | Copper Alloy | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | 0.25 Ám | 10 Áin | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | Cantilever | Non Specified - Single Edge | 3.96 mm | 0.156 in | 30 | Single | Through Hole | Gold | 125 °C | -40 C | Green | Copper Alloy | 1 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 30 | 0.25 Ám | 10 Áin | Solder | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | Cantilever | Non Specified - Single Edge | 3.96 mm | 0.156 in | 30 | Single | Through Hole | Gold | 125 °C | -40 C | Green | Copper Alloy | 1 | 1 | 0.128 " | 3.25 mm |
