HD/RD74HC Series
| Part | Output Type | Voltage - Supply [Min] | Voltage - Supply [Max] | Number of Bits per Element | Number of Elements | Operating Temperature [Min] | Operating Temperature [Max] | Current - Output High, Low [custom] | Current - Output High, Low [custom] | Logic Type |
|---|---|---|---|---|---|---|---|---|---|---|
 Renesas Electronics Corporation | 3-State | 2 V | 6 V | 4 | 2 | -40 °C | 125 °C | 7.8 mA | 7.8 mA | Buffer Non-Inverting |
 Renesas Electronics Corporation | 3-State | 2 V | 6 V | 4 | 2 | -40 °C | 125 °C | 7.8 mA | 7.8 mA | Buffer Non-Inverting |
Description
AI
The most standard series of the family of 5V drive bipolar general-purpose logic ICs. It has an over 20-year track record and high market penetration.
