313SX2 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
MICROSWITCH, SUBMINIATURE, LEAF LEVER, SPDT, SOLDER, 1 A, 30 VDC
| Part | Voltage Rating - DC | Operating Position | Operating Position | Switch Function | Circuit | Termination Style | Voltage Rating - AC | Overtravel [custom] | Overtravel [custom] | Mechanical Life | Actuator Type | Operating Force | Pretravel | Pretravel | Release Force | Current Rating (Amps) | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | 30 V | 8.25 mm | 0.325 in | On-Mom | SPDT | Solder Turret | 125 V | 0.025 in | 0.6 mm | 10000000 Cycles | Lever Straight | 30 gf | 2.9 mm | 0.114 in | 5.099 gf | 1 A | Chassis Mount | -55 C | 125 °C |
