HEA2-5 Series

Catalog

DC DC CONVERTER +/-15V 2W

Part	Mounting Type	Voltage - Isolation	Number of Outputs	Package / Case	Power (Watts)	Voltage - Input (Max) [Max]	Current - Output (Max)	Current - Output (Max)	Approval Agency	Applications	Features	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Voltage - Input (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 1	Voltage - Output 2	Type	Efficiency	Current - Output (Max) [Max]
Daburn Electronics HEA2-5-15	Through Hole	1.6 kV	2	8-SIP Module 7 Leads	2 W	13.2 V	67 mA	67 mA	CE	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	4.5 V	105 C	-40 °C	15 V	-15 V	Isolated Module	84 %
Daburn Electronics HEA2-5S12	Through Hole	1.6 kV	1	8-SIP Module 7 Leads	2 W	13.2 V			CE	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	4.5 V	105 C	-40 °C	12 V		Isolated Module	84 %	167 mA
Daburn Electronics HEA2-5-5	Through Hole	1.6 kV	2	8-SIP Module 7 Leads	2 W	13.2 V			CE	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	4.5 V	105 C	-40 °C	5 V	-5 V	Isolated Module	81 %
Daburn Electronics HEA2-5-12	Through Hole	1.6 kV	2	8-SIP Module 7 Leads	2 W	13.2 V	83 mA	83 mA	CE	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	4.5 V	105 C	-40 °C	12 V	-12 V	Isolated Module	85 %
Daburn Electronics HEA2-5S5	Through Hole	1.6 kV	1	8-SIP Module 7 Leads	2 W	13.2 V			CE	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	4.5 V	105 C	-40 °C	5 V		Isolated Module	81 %	400 mA
Daburn Electronics HEA2-5S33	Through Hole	1.6 kV	1	8-SIP Module 7 Leads	1.7 W	13.2 V			CE	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	4.5 V	105 C	-40 °C	3.3 V		Isolated Module	78 %	500 mA
Daburn Electronics HEA2-5S9	Through Hole	1.6 kV	1	8-SIP Module 7 Leads	2 W	13.2 V			CE	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	4.5 V	105 C	-40 °C	9 V		Isolated Module	84 %	222 mA
Daburn Electronics HEA2-5S15	Through Hole	1.6 kV	1	8-SIP Module 7 Leads	2 W	13.2 V			CE	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	4.5 V	105 C	-40 °C	15 V		Isolated Module	84 %	134 mA
Daburn Electronics HEA2-5S24	Through Hole	1.6 kV	1	8-SIP Module 7 Leads	2 W	13.2 V			CE	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	4.5 V	105 C	-40 °C	24 V		Isolated Module	85 %	83 mA
