RP110 Series

Catalog

LINE FILTER 250VAC 10A CHASSIS

Part	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Applications	Filter Type	Voltage - Rated AC	Approval Agency	Current	Frequency - Operating [Max]	Frequency - Operating [Min]	Termination Style	Configuration
Astrodyne TDI RP110-10-.47-QD	100 °C	-25 °C	Chassis Mount	General Purpose	Single Phase	250 V	CE cURus SEMKO	10 A	60 Hz	50 Hz	Quick Connect	Single Stage
Astrodyne TDI RP110-20-.47-W	100 °C	-25 °C	Chassis Mount	General Purpose	Single Phase	250 V	CE cURus SEMKO	20 A	60 Hz	50 Hz	Wire Leads	Single Stage
Astrodyne TDI RP110-30-4.7-S	100 °C	-25 °C	Chassis Mount	General Purpose	Single Phase	250 V	CE cURus SEMKO	30 A	60 Hz	50 Hz	Threaded Post (M4)	Single Stage
Astrodyne TDI RP110-30-1-W	100 °C	-25 °C	Chassis Mount	General Purpose	Single Phase	250 V	CE cURus SEMKO	30 A	60 Hz	50 Hz	Wire Leads	Single Stage
Astrodyne TDI RP110-20-0-W	100 °C	-25 °C	Chassis Mount	General Purpose	Single Phase	250 V	CE cURus SEMKO	20 A	60 Hz	50 Hz	Wire Leads	Single Stage
Astrodyne TDI RP110-10-1-W	100 °C	-25 °C	Chassis Mount	General Purpose	Single Phase	250 V	CE cURus SEMKO	10 A	60 Hz	50 Hz	Wire Leads	Single Stage
Astrodyne TDI RP110-20-.47-QD	100 °C	-25 °C	Chassis Mount	General Purpose	Single Phase	250 V	CE cURus SEMKO	20 A	60 Hz	50 Hz	Quick Connect	Single Stage
Astrodyne TDI RP110-6-2.2-QD	100 °C	-25 °C	Chassis Mount	General Purpose	Single Phase	250 V	CE cURus SEMKO	6 A	60 Hz	50 Hz	Quick Connect	Single Stage
Astrodyne TDI RP110-20-0-S	100 °C	-25 °C	Chassis Mount	General Purpose	Single Phase	250 V	CE cURus SEMKO	20 A	60 Hz	50 Hz	Threaded Post (M4)	Single Stage
Astrodyne TDI RP110-6-.47-W	100 °C	-25 °C	Chassis Mount	General Purpose	Single Phase	250 V	CE cURus SEMKO	6 A	60 Hz	50 Hz	Wire Leads	Single Stage
