59M Series

Catalog

ROTARY SWITCHES 59M18-01-9-02N

Part	Number of Decks [custom]	Contact Finish	Index Stops	Contact Timing	Voltage Rating - AC	Circuit per Deck	Actuator Length [x]	Actuator Type	Current Rating (Amps)	Number of Positions	Angle of Throw	Voltage Rating - DC	Mounting Type	Contact Material	Depth Behind Panel [z]	Number of Poles per Deck	Termination Style	Number of Decks
Grayhill Inc. 59M18-01-9-02N	1	Gold	Fixed	Non-Shorting (BBM)	115 V	9PDT	11.1 mm	Flatted (6.35mm Dia)	250 mA	2	18 °	30 V	Panel Mount	Silver Alloy	23.27 mm	9	Solder Lug
Grayhill Inc. 59M18-02-1-17N		Gold	Fixed	Non-Shorting (BBM)	115 V	SP17T	11.1 mm	Flatted (6.35mm Dia)	250 mA		18 °	30 V	Panel Mount	Silver Alloy	31.72 mm	1	Solder Lug	2
Grayhill Inc. 59M18-12-2-10N		Gold	Fixed	Non-Shorting (BBM)	115 V	DP10T	11.1 mm	Flatted (6.35mm Dia)	250 mA	10	18 °	30 V	Panel Mount	Silver Alloy		2	Solder Lug	12
Grayhill Inc. 59M18-03B20N		Gold	Fixed	Non-Shorting (BBM)	115 V	SP20T	11.1 mm	Flatted (6.35mm Dia)	250 mA	20	18 °	30 V	Panel Mount	Silver Alloy	40.18 mm	1	Solder Lug	3
Grayhill Inc. 59M18-05B20N		Gold	Fixed	Non-Shorting (BBM)	115 V	SP20T	11.1 mm	Flatted (6.35mm Dia)	250 mA	20	18 °	30 V	Panel Mount	Silver Alloy	57.1 mm	1	Solder Lug	5
Grayhill Inc. 59M18-06A20N		Gold	Continuous	Non-Shorting (BBM)	115 V	SP20T	11.1 mm	Flatted (6.35mm Dia)	250 mA	20	18 °	30 V	Panel Mount	Silver Alloy	71.91 mm	1	Solder Lug	6
Grayhill Inc. 59M18-01A20N	1	Gold	Continuous	Non-Shorting (BBM)	115 V	SP20T	11.1 mm	Flatted (6.35mm Dia)	250 mA	20	18 °	30 V	Panel Mount	Silver Alloy	23.27 mm	1	Solder Lug
Grayhill Inc. 59M18-01-1-03N	1	Gold	Fixed	Non-Shorting (BBM)	115 V	SP3T	11.1 mm	Flatted (6.35mm Dia)	250 mA		18 °	30 V	Panel Mount	Silver Alloy	23.27 mm	1	Solder Lug
