LB15SKW01 Series

Catalog

PUSHBUTTON SWITCH, LB SERIES, SPDT, ON-(ON), SQUARE, TRANSPARENT

Part	Mechanical Life	Electrical Life	Illumination Type, Color	Mounting Type	Voltage Rating - AC	Type	Current Rating (Amps)	Termination Style	Illumination Voltage (Nominal)	Circuit	Switch Function	Actuator Type	Actuator Marking	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating - DC	Color - Actuator/Cap
NKK Switches LB15SKW01-6F-JB	1000000 Cycles	100000 Cycles	Green LED	Panel Mount Snap-In	125 V	Illuminated Standard	3 A	Solder Quick Connect - 0.110" (2.8mm)	3.3 VDC	SPDT	On-Mom	Button Square	No Marking	16.2 mm	16.2 mm	50 °C	-25 °C	30 V	Clear
NKK Switches LB15SKW01-5D-JD	1000000 Cycles	100000 Cycles	Amber LED	Panel Mount Snap-In	125 V	Illuminated Standard	3 A	Solder Quick Connect - 0.110" (2.8mm)	2 VDC	SPDT	On-Mom	Button Square	No Marking	16.2 mm	16.2 mm	50 °C	-25 °C	30 V	Clear
NKK Switches LB15SKW01-1C-A	1000000 Cycles	100000 Cycles	LED Red	Panel Mount Snap-In	125 V	Illuminated Standard	3 A	Solder Quick Connect - 0.110" (2.8mm)	1.9 VDC	SPDT	On-Mom	Button Square	No Marking	16.2 mm	16.2 mm	50 °C	-25 °C	30 V	Black
NKK Switches LB15SKW01-5F-JF	1000000 Cycles	100000 Cycles	Green LED	Panel Mount Snap-In	125 V	Illuminated Standard	3 A	Solder Quick Connect - 0.110" (2.8mm)	2.1 VDC	SPDT	On-Mom	Button Square	No Marking	16.2 mm	16.2 mm	50 °C	-25 °C	30 V	Clear
NKK Switches LB15SKW01-1D-A	1000000 Cycles	100000 Cycles	Amber LED	Panel Mount Snap-In	125 V	Illuminated Standard	3 A	Solder Quick Connect - 0.110" (2.8mm)	2 VDC	SPDT	On-Mom	Button Square	No Marking	16.2 mm	16.2 mm	50 °C	-25 °C	30 V	Black
NKK Switches LB15SKW01-5D05-JD	1000000 Cycles	100000 Cycles	Amber LED	Panel Mount Snap-In	125 V	Illuminated Standard	3 A	Solder Quick Connect - 0.110" (2.8mm)	5 VDC	SPDT	On-Mom	Button Square	No Marking	16.2 mm	16.2 mm	50 °C	-25 °C	30 V	Clear
NKK Switches LB15SKW01-5F24-JF	1000000 Cycles	100000 Cycles	Green LED	Panel Mount Snap-In	125 V	Illuminated Standard	3 A	Solder Quick Connect - 0.110" (2.8mm)	24 V	SPDT	On-Mom	Button Square	No Marking	16.2 mm	16.2 mm	50 °C	-25 °C	30 V	Clear
NKK Switches LB15SKW01-5F05-JF	1000000 Cycles	100000 Cycles	Green LED	Panel Mount Snap-In	125 V	Illuminated Standard	3 A	Solder Quick Connect - 0.110" (2.8mm)	5 VDC	SPDT	On-Mom	Button Square	No Marking	16.2 mm	16.2 mm	50 °C	-25 °C	30 V	Clear
NKK Switches LB15SKW01-5C24-JC	1000000 Cycles	100000 Cycles	LED Red	Panel Mount Snap-In	125 V	Illuminated Standard	3 A	Solder Quick Connect - 0.110" (2.8mm)	24 V	SPDT	On-Mom	Button Square	No Marking	16.2 mm	16.2 mm	50 °C	-25 °C	30 V	Clear
NKK Switches LB15SKW01-5D12-JD	1000000 Cycles	100000 Cycles	Amber LED	Panel Mount Snap-In	125 V	Illuminated Standard	3 A	Solder Quick Connect - 0.110" (2.8mm)	12 VDC	SPDT	On-Mom	Button Square	No Marking	16.2 mm	16.2 mm	50 °C	-25 °C	30 V	Clear
