2112 Series

Manufacturer: Oupiin

Catalog

PIN HEADER, SINGLE ROW, 2 PIN, R

Part	Contact Finish Thickness - Post	Contact Shape	Insulation Material	Contact Length - Post [x]	Contact Length - Post [x]	Number of Positions Loaded	Termination	Contact Finish - Post	Contact Length - Post [custom]	Contact Length - Post	Contact Material	Number of Positions	Contact Length - Mating	Contact Length - Mating	Insulation Height [z]	Insulation Height [z]	Contact Finish - Mating	Contact Type	Connector Type	Shrouding	Pitch - Mating	Pitch - Mating	Fastening Type	Mounting Type	Contact Finish Thickness - Mating	Material Flammability Rating	Number of Rows	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Color	Overall Contact Length	Overall Contact Length	Number of Rows [custom]	Row Spacing - Mating	Row Spacing - Mating	Current Rating (Amps)	Contact Length - Post
Oupiin 2112-1X02G00RB	Flash	Square	Polybutylene Terephthalate (PBT)	0.11 in	2.8 mm	All	Solder	Gold	0.11 in	2.79 mm	Brass	2	0.154 in	3.9 mm	2 mm	0.079 in	Gold	Male Pin	Header	Unshrouded	0.079 "	2 mm	Push-Pull	Right Angle Through Hole	Flash	UL94 V-0	1	-40 C	105 ░C	Black
Oupiin 2112-2X03G00SB	Flash	Square	Polybutylene Terephthalate (PBT)	0.11 in	2.8 mm	All	Solder	Gold	0.11 in	2.79 mm	Brass	6	0.154 in	3.9 mm	2 mm	0.079 in	Gold	Male Pin	Header Header Cuttable	Unshrouded	0.079 "	2 mm	Push-Pull	Through Hole	Flash	UL94 V-0		-40 C	105 ░C	Black	0.343 in	8.7 mm	2	2 mm	0.079 in
Oupiin 2112-2X20G00SB	Flash	Square	Polybutylene Terephthalate (PBT)	0.11 in	2.8 mm	All	Solder	Gold	0.11 in	2.79 mm	Brass	40	0.154 in	3.9 mm	2 mm	0.079 in	Gold	Male Pin	Header Header Cuttable	Unshrouded	0.079 "	2 mm	Push-Pull	Through Hole	Flash	UL94 V-0		-40 C	105 ░C	Black	0.343 in	8.7 mm	2	2 mm	0.079 in
Oupiin 2112-2X05G00SB	Flash	Square	Polybutylene Terephthalate (PBT)	0.11 in	2.8 mm	All	Solder	Gold	0.11 in	2.79 mm	Brass	10	0.154 in	3.9 mm	2 mm	0.079 in	Gold	Male Pin	Header Header Cuttable	Unshrouded	0.079 "	2 mm	Push-Pull	Through Hole	Flash	UL94 V-0		-40 C	105 ░C	Black	0.343 in	8.7 mm	2	2 mm	0.079 in
Oupiin 2112-2X15G00SB	Flash	Square	Polybutylene Terephthalate (PBT)	0.11 in	2.8 mm	All	Solder	Gold	0.11 in	2.79 mm	Brass	30	0.154 in	3.9 mm	2 mm	0.079 in	Gold	Male Pin	Header Header Cuttable	Unshrouded	0.079 "	2 mm	Push-Pull	Through Hole	Flash	UL94 V-0		-40 C	105 ░C	Black	0.343 in	8.7 mm	2	2 mm	0.079 in
Oupiin 2112-2X40G00SB	Flash	Square	Polybutylene Terephthalate (PBT)	0.11 in	2.8 mm	All	Solder	Gold	0.11 in	2.79 mm	Brass	80	0.154 in	3.9 mm	2 mm	0.079 in	Gold	Male Pin	Header Header Cuttable	Unshrouded	0.079 "	2 mm	Push-Pull	Through Hole	Flash	UL94 V-0		-40 C	105 ░C	Black	0.343 in	8.7 mm	2	2 mm	0.079 in
Oupiin 2112-1X40G00SB	Flash	Square	Polybutylene Terephthalate (PBT)	0.11 in	2.8 mm	All	Solder	Gold	0.11 in	2.79 mm	Brass	40	0.154 in	3.9 mm	2 mm	0.079 in	Gold	Male Pin	Header Header Cuttable	Unshrouded	0.079 "	2 mm	Push-Pull	Through Hole	Flash	UL94 V-0	1	-40 C	105 ░C	Black	0.343 in	8.7 mm				3 A
Oupiin 2112-2X07G00SB	Flash	Square	Polybutylene Terephthalate (PBT)	0.11 in	2.8 mm	All	Solder	Gold	0.11 in	2.79 mm	Brass	14	0.154 in	3.9 mm	2 mm	0.079 in	Gold	Male Pin	Header Header Cuttable	Unshrouded	0.079 "	2 mm	Push-Pull	Through Hole	Flash	UL94 V-0		-40 C	105 ░C	Black	0.343 in	8.7 mm	2	2 mm	0.079 in
Oupiin 2112-2X02G00SB	Flash	Square	Polybutylene Terephthalate (PBT)	0.11 in	2.8 mm	All	Solder	Gold	0.11 in	2.79 mm	Brass	4	0.154 in	3.9 mm	2 mm	0.079 in	Gold	Male Pin	Header Header Cuttable	Unshrouded	0.079 "	2 mm	Push-Pull	Through Hole	Flash	UL94 V-0		-40 C	105 ░C	Black	0.343 in	8.7 mm	2	2 mm	0.079 in
Oupiin 2112-2X05G00S-3-3B	Flash	Square	Polybutylene Terephthalate (PBT)			All	Solder	Gold		3 mm	Brass	10	0.118 in	3 mm	2 mm	0.079 in	Gold	Male Pin	Header Header Cuttable	Unshrouded	0.079 "	2 mm	Push-Pull	Through Hole	Flash	UL94 V-0		-40 C	105 ░C	Black	0.315 in	8 mm	2	2 mm	0.079 in		0.118 in
