845-043 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 43POS 0.100
| Part | Material - Insulation | Termination Rows | Number of Rows | Contact Finish | Card Type | Contact Material | Mounting Type | Contact Type | Termination | Color | Read Out | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Flange Feature | Number of Positions | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Gold | Non Specified - Single Edge | Copper Alloy | Through Hole | Cantilever | Solder | Green | Single | Female | 125 °C | -40 C | 0.1 " | 2.54 mm | 4-40 Threaded Insert Top Mount Opening | 43 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Gold | Non Specified - Single Edge | Copper Alloy | Right Angle Through Hole | Cantilever | Solder | Green | Single | Female | 125 °C | -40 C | 0.1 " | 2.54 mm | 43 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Gold | Non Specified - Single Edge | Copper Alloy | Through Hole | Cantilever | Solder | Green | Single | Female | 125 °C | -40 C | 0.1 " | 2.54 mm | Flush Mount Top Opening Unthreaded | 43 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Gold | Non Specified - Single Edge | Copper Alloy | Through Hole | Cantilever | Solder | Green | Single | Female | 125 °C | -40 C | 0.1 " | 2.54 mm | 43 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Gold | Non Specified - Single Edge | Copper Alloy | Through Hole | Cantilever | Solder | Green | Single | Female | 125 °C | -40 C | 0.1 " | 2.54 mm | 43 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Gold | Non Specified - Single Edge | Copper Alloy | Right Angle Through Hole | Cantilever | Solder | Green | Single | Female | 125 °C | -40 C | 0.1 " | 2.54 mm | 43 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Gold | Non Specified - Single Edge | Copper Alloy | Through Hole | Cantilever | Wire Wrap | Green | Single | Female | 125 °C | -40 C | 0.1 " | 2.54 mm | Flush Mount Side Opening Unthreaded | 43 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Gold | Non Specified - Single Edge | Copper Alloy | Right Angle Through Hole | Cantilever | Solder | Green | Single | Female | 125 °C | -40 C | 0.1 " | 2.54 mm | 4-40 Flush Mount Threaded Insert Top Opening | 43 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Gold | Non Specified - Single Edge | Copper Alloy | Through Hole | Cantilever | Wire Wrap | Green | Single | Female | 125 °C | -40 C | 0.1 " | 2.54 mm | M3 Threaded Insert Top Mount Opening | 43 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Gold | Non Specified - Single Edge | Copper Alloy | Right Angle Through Hole | Cantilever | Solder | Green | Single | Female | 125 °C | -40 C | 0.1 " | 2.54 mm | 4-40 Threaded Insert Top Mount Opening | 43 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin |
